KARIMUN WAGON R TIPE 1 & 2

Preview Engine Transmission Electrical Suspension Body
< KEMBALI KE THUMBNAIL FIG. 22 MT CLUTCH (5MT)FIG. 23 MT TRANSMISSION GEAR (5MT)FIG. 24 MT TRANSMISSION CASE (TYPE 1:5MT)FIG. 24A MT TRANSMISSION CASE (TYPE 2:5MT)FIG. 25 MT GEAR SHIFT FORK (5MT)FIG. 25A AGS CLUTCH (5AGS)FIG. 25B AGS TRANSMISSION GEAR (5AGS)FIG. 25C AGS TRANSMISSION CASE (5AGS)FIG. 25D AGS GEAR SHIFT FORK (5AGS)FIG. 25E AGS ACTUATOR (5AGS)FIG. 26 GEAR SHIFT CONTROL (TYPE 1:5MT)FIG. 26A GEAR SHIFT CONTROL (TYPE 2:5MT)FIG. 26B SELECT LEVER (5AGS)FIG. 27 FRONT DIFFERENTIAL GEAR (5MT)FIG. 27A FRONT DIFFERENTIAL GEAR (5AGS)

FIG. 22 MT CLUTCH (5MT)

FIG. 22 MT CLUTCH (5MT)
No No. Part Description Qty Price Per Pcs Remarks
1 22100-67K20-000
SUB: 22100B67K20N000		 COVER ASSY, CLUTCH 1 Rp419.500
2 22400-67K20-000
SUB: 22400B67K20N000		 DISC, CLUTCH 1 Rp446.000
3 01550-0816A-000
SUB: 01550B0816AN000		 BOLT (8X16) 6 Rp6.000
4 23260-63J01-000 SHAFT, CLUTCH RELEASE 1 Rp370.000
5 23266M68K02-000 ARM, CLUTCH RELEASE 1 Rp234.500
6 23269-51K00-000 SPRING, RELEASE SHAFT RETURN 1 Rp39.500
7 09205-03019-000 SPRING PIN (3X10) 1 Rp9.500
8 09269-28004-000
SUB: 09269B28004N000		 BEARING (28X58X22) 1 Rp240.500
9 09284M16004-000 OIL SEAL (16X24X5) 1 Rp19.500
10 23264M60B00-000
SUB: 09300M16009-000		 BUSH (16X20X20) 1 Rp23.500
11 23264M60B20-000
SUB: 09300M16010-000		 BUSH (16X24X19) 1 Rp25.000
12 01550-0830A-000
SUB: 01550B0830AN000		 BOLT 1 Rp4.000
13 23710-67L21-000
SUB: 23710B67L21N000		 CABLE ASSY, CLUTCH 1 Rp157.000
14 23913M68K00-000 PIN, CLUTCH CABLE JOINT 1 Rp8.500
15 23915-67L20-000
SUB: 23915B67L20N000		 CLAMP, CLUTCH CABLE NO.1 1 Rp11.000
16 23916-67L20-000
SUB: 23916B67L20N000		 CLAMP, CLUTCH CABLE NO.2 1 Rp11.000
17 23917-67L00-000 CLAMP 1 Rp21.500
18 23922-76G00-000 CAP, CLUTCH CABLE JOINT LOCK 1 Rp19.500
19 09150-06010-000
SUB: 09150B06010N000		 NUT 1 Rp4.500
20 23910M67L00-000 BRACKET, CLUTCH CABLE 1 Rp182.500
21 01550-0816A-000
SUB: 01550B0816AN000		 BOLT 2 Rp6.000
22 08316-1006A-000
SUB: 08316B1006AN000		 NUT 2 Rp2.000

*Harga dapat berubah sewaktu-waktu tanpa pemberitahuan terlebih dahulu.
