ALL NEW ERTIGA SUZUKI SPORT

Preview Engine Transmission Electrical Suspension Body
< KEMBALI KE THUMBNAIL FIG.260A-GEAR SHIFT CONTROL (5MT)FIG.260B-GEAR SHIFT CONTROL (4AT)FIG.264A-SELECT LEVER (4AT)FIG.226A-INTERMEDIATE SHAFT (5MT)FIG.226B-INTERMEDIATE SHAFT (4AT)FIG.272A-FRONT DIFFERENTIAL GEAR (5MT)FIG.272B-FRONT DIFFERENTIAL GEAR (4AT)FIG.300A-ENGINE ELECTRICALFIG.302A-STARTING MOTORFIG.304A-STARTING MOTORFIG.320A-BATTERY (5MT)FIG.320B-BATTERY (4AT)FIG324A-SPEEDOMETER ((GA,GL):5MT)FIG.324B-SPEEDOMETER (GX:5MT)FIG.324C-SPEEDOMETER (GL:4AT)FIG.324D-SPEEDOMETER (GL:4AT)FID.330A-HEADLAMPFIG.332A-FRONT FOG LAMP (W_FR_FOG)FIG.336A-REAR LAMPFIG.338A-ROOM LAMP (GA)FIG.344A-ENGINE ROOM HARNESS (5MT)FIG.348A-ENGINE ROOM HARNESS (4AT)FIG.348B-ENGINE HARNESS BRACKET (5MT)FIG.350A-ENGINE HARNESS BRACKET (4AT)FIG.351A-ELECTRICAL CONTROL INSTRUMENTAL PANELFIG.360B-LOCK SET (N_PU_STA:4AT)FIG.360C-LOCK SET (W_PU_STA)FIG.370A-FRONT WINDOW WIPERFIG.376A-WINDOW WASHERFIG.374A-REAR WINDOW WIPERFIG.392A-WINDOW WASHERFIG.392B-AUDIO (N_TUNER)FIG.400A-AUDIO (W_TUNER)FIG.408A-FRONT SUSPENSIONFIG.410A-FRONT DRIVE SHAFT (5MT)FIG.418A-FRONT SUSPENSION FRAMEFIG.430A-REAR SUSPENSIONFIG.449A-ROAD WHEEL/TIRE (GA)FIG.449B-ROAD WHEEL/TIRE (GL)FIG.449C-ROAD WHEEL/TIRE (GX)FIG.451A-STEERING WHEEL (GA)FIG.451B-STEERING WHEEL (GL)FIG.451C-STEERING WHEEL (GX)FIG.453A-STEERING COLUMN (N_PU_STA)FIG.453B-STEERING COLUMN (W_PU_STA)FIG.480A-STEERING UNITFIG.338B-ROOM LAMP (GL,GX) FIG.344B-ENGINE ROOM HARNESS (4AT)FIG.360A-LOCK SET (N_PU_STA:5MT)FIG.410B-FRONT DRIVE SHAFT (4AT)

FIG.400A-AUDIO (W_TUNER)

FIG.400A-AUDIO (W_TUNER)
No No. Part Description Qty Price Per Pcs Remarks
1 45111-73R00-000 KNUCKLE,STRG,R 1 Rp555.000
2 45151-73R00-000 KNUCKLE,STRG,L 1 Rp555.000
3 41601-73R31-000
SUB: 41601-73R00-000		 STRUT ASSY,FR SPNSN,R 1 Rp1.107.500
4 41602-73R31-000
SUB: 41602-73R00-000		 STRUT ASSY,FR SPNSN,L 1 Rp1.107.500
5 41710-72R00-000 SUPPORT,FR STRUT 2 Rp175.500
6 41711-52R00-000 PLATE,STRUT BEARING 2 Rp149.500
7 41720M72R00-000 STOPPER,FR STRUT REBOUND 2 Rp59.000
8 41721-55R00-000 NUT,STRUT SUPPORT LWR 2 Rp69.000
9 41724-72R00-000 CAP,STRUT ROD 2 Rp141.000
10 41742M57K10-000
SUB: 41742-57K00-000		 BEARING,FR STRUT 2 Rp81.000
11 41931-55R01-000
SUB: 41931-55R00-000		 COVER,STRUT DUST 2 Rp200.500
12 09103-12118-000 BOLT (12X50) 4 Rp33.000
13 08316-1012A-000
SUB: 09159-12064-000		 NUT (M12) 4 Rp6.500
14 08310-0012A-000 NUT 2 Rp17.500
15-1 41111-73R00-000 SPRING,FR COIL 2 Rp961.500
15-2 41111-73R10-000 SPRING,FR COIL 2 Rp961.500
16 42111M72R01-000
SUB: 42111-72R00-000		 STOPPER,FR BUMP 2 Rp137.000
17 41212-52R00-000 SEAT,FR SPRING LWR 2 Rp105.000
18 41230-55R00-000 SEAT,FR SPRING UPR 2 Rp101.000
19 45201-73R00-000 ARM ASSY,FR SPNSN,R 1 Rp864.500
20 45202-73R00-000 ARM ASSY,FR SPNSN,L 1 Rp864.500
21 45861-73R10-000 BOLT,SPNSN ARM FR BUSHING 2 Rp25.500
22 09159-12069-000 NUT (M12) 2 Rp23.000
23 09385-12002-000
SUB: 09385B12002N000		 PIN,SNAP 2 Rp4.500
24 43401-68R00-000 HUB ASSY,FR WHEEL 2 Rp813.000
25 09119-12012-000 .BOLT (12X38) 10 Rp14.500
26 43458-73R00-000 BOLT,WHEEL HUB HOUSING 6 Rp11.000
27 43459-68R00-000 NUT (M22) 2 Rp125.500

*Harga dapat berubah sewaktu-waktu tanpa pemberitahuan terlebih dahulu.
