ALL NEW ERTIGA SUZUKI SPORT

Preview Engine Transmission Electrical Suspension Body
< KEMBALI KE THUMBNAIL FIG.260A-GEAR SHIFT CONTROL (5MT)FIG.260B-GEAR SHIFT CONTROL (4AT)FIG.264A-SELECT LEVER (4AT)FIG.226A-INTERMEDIATE SHAFT (5MT)FIG.226B-INTERMEDIATE SHAFT (4AT)FIG.272A-FRONT DIFFERENTIAL GEAR (5MT)FIG.272B-FRONT DIFFERENTIAL GEAR (4AT)FIG.300A-ENGINE ELECTRICALFIG.302A-STARTING MOTORFIG.304A-STARTING MOTORFIG.320A-BATTERY (5MT)FIG.320B-BATTERY (4AT)FIG324A-SPEEDOMETER ((GA,GL):5MT)FIG.324B-SPEEDOMETER (GX:5MT)FIG.324C-SPEEDOMETER (GL:4AT)FIG.324D-SPEEDOMETER (GL:4AT)FID.330A-HEADLAMPFIG.332A-FRONT FOG LAMP (W_FR_FOG)FIG.336A-REAR LAMPFIG.338A-ROOM LAMP (GA)FIG.344A-ENGINE ROOM HARNESS (5MT)FIG.348A-ENGINE ROOM HARNESS (4AT)FIG.348B-ENGINE HARNESS BRACKET (5MT)FIG.350A-ENGINE HARNESS BRACKET (4AT)FIG.351A-ELECTRICAL CONTROL INSTRUMENTAL PANELFIG.360B-LOCK SET (N_PU_STA:4AT)FIG.360C-LOCK SET (W_PU_STA)FIG.370A-FRONT WINDOW WIPERFIG.376A-WINDOW WASHERFIG.374A-REAR WINDOW WIPERFIG.392A-WINDOW WASHERFIG.392B-AUDIO (N_TUNER)FIG.400A-AUDIO (W_TUNER)FIG.408A-FRONT SUSPENSIONFIG.410A-FRONT DRIVE SHAFT (5MT)FIG.418A-FRONT SUSPENSION FRAMEFIG.430A-REAR SUSPENSIONFIG.449A-ROAD WHEEL/TIRE (GA)FIG.449B-ROAD WHEEL/TIRE (GL)FIG.449C-ROAD WHEEL/TIRE (GX)FIG.451A-STEERING WHEEL (GA)FIG.451B-STEERING WHEEL (GL)FIG.451C-STEERING WHEEL (GX)FIG.453A-STEERING COLUMN (N_PU_STA)FIG.453B-STEERING COLUMN (W_PU_STA)FIG.480A-STEERING UNITFIG.338B-ROOM LAMP (GL,GX) FIG.344B-ENGINE ROOM HARNESS (4AT)FIG.360A-LOCK SET (N_PU_STA:5MT)FIG.410B-FRONT DRIVE SHAFT (4AT)

FIG.350A-ENGINE HARNESS BRACKET (4AT)

FIG.350A-ENGINE HARNESS BRACKET (4AT)
No No. Part Description Qty Price Per Pcs Remarks
1 37670M56R00-000 SWITCH ASSY,DOOR 4 Rp54.000
1 37670M56R00-000 SWITCH ASSY,DOOR 4 Rp54.000
2 03541-0410A-000 SCREW 6 Rp11.000
2 03541-0410A-000 SCREW 6 Rp11.000
3 37990-73RA2-000
SUB: 37990-73RA0-000		 SWITCH ASSY,POWER WINDOW MA 1 Rp601.000
3 37990-73RA2-000
SUB: 37990-73RA0-000		 SWITCH ASSY,POWER WINDOW MA 1 Rp601.000
4 37995M79M02-000
SUB: 37995M79M00-000		 SWITCH ASSY,POWER WINDOW SUB 3 Rp109.500
4 37995M79M02-000
SUB: 37995M79M00-000		 SWITCH ASSY,POWER WINDOW SUB 3 Rp109.500
5-2 37950-62J31-000 SWITCH ASSY,MIRROR 1 Rp463.500
5-1 37950-62J21-000 SWITCH ASSY,MIRROR 1 Rp278.500
5-1 37950-62J21-000 SWITCH ASSY,MIRROR 1 Rp278.500
5-2 37950-62J31-000 SWITCH ASSY,MIRROR 1 Rp463.500
6 95643-74P00-000 SENSOR,OUTSIDE AIR TEMP 1 Rp280.000
6 95643-74P00-000 SENSOR,OUTSIDE AIR TEMP 1 Rp280.000
7 37175-73R00-000 ANTENNA ASSY,KLS 1 Rp65.500
7 37175-73R00-000 ANTENNA ASSY,KLS 1 Rp65.500
8 37175-73R00-000 ANTENNA ASSY,KLS 1 Rp65.500
8 37175-73R00-000 ANTENNA ASSY,KLS 1 Rp65.500
9 37175-73R00-000 ANTENNA ASSY,KLS 1 Rp65.500
9 37175-73R00-000 ANTENNA ASSY,KLS 1 Rp65.500
10 38500-73R00-000 HORN ASSY,LOW PITCHED 1 Rp73.000
10 38500-73R00-000 HORN ASSY,LOW PITCHED 1 Rp73.000
11 38500-73R10-000 HORN ASSY,HIGH PITCHED 1 Rp80.500
11 38500-73R10-000 HORN ASSY,HIGH PITCHED 1 Rp80.500
12 09115-08001-000 BOLT (8X18) 2 Rp21.500
12 09115-08001-000 BOLT (8X18) 2 Rp21.500
13 02162-0620A-000
SUB: 02162-0620C-000		 SCREW 1 Rp5.500
13 02162-0620A-000
SUB: 02162-0620C-000		 SCREW 1 Rp5.500
14 38930-73R00-000 SENSOR ASSY,FORWARD RIGHT 1 Rp137.500
14 38930-73R00-000 SENSOR ASSY,FORWARD RIGHT 1 Rp137.500
15 37177M66R10-000 SWITCH ASSY,BACK DOOR KLS 1 Rp184.000
15 37177M66R10-000 SWITCH ASSY,BACK DOOR KLS 1 Rp184.000
16 09250-16015-000
SUB: 09250B16015N000		 PLUG (OD:24.5) 1 Rp3.500
16 09250-16015-000
SUB: 09250B16015N000		 PLUG (OD:24.5) 1 Rp3.500
17 37285M76M00-5PK CAP, MIRROR SWITCH HOLE (BLACK 1 Rp33.500
17 37285M76M00-5PK CAP, MIRROR SWITCH HOLE (BLACK 1 Rp33.500
18 36771-79M01-000 LABEL,SECURITY ALARM 1 Rp5.000
18 36771-79M01-000 LABEL,SECURITY ALARM 1 Rp5.000
19 37730-73R00-000 CONTROLLER ASSY,PARK SNSR 1 Rp371.500
19 37730-73R00-000 CONTROLLER ASSY,PARK SNSR 1 Rp371.500
20 37734M56R00-000 BUZZER,PARK SNSR 1 Rp93.500
20 37734M56R00-000 BUZZER,PARK SNSR 1 Rp93.500
21-2 37735-73R00-Z2S SENSOR ASSY,PARK (SILVER) 2 Rp192.500
21-3 37735-73R00-ZYZ SENSOR ASSY,PARK (GRAY) 2 Rp197.500
21-4 37735-73R00-ZBD SENSOR ASSY,PARK (BLACK) 2 Rp192.500
21-5 37735-73R00-ZKB SENSOR ASSY,PARK (RED) 2 Rp197.500
21-6 37735-73R00-ZLL SENSOR ASSY,PARK (RED) 2 Rp197.500
21-7 37735-73R00-ZZA SENSOR ASSY,PARK (BROWN) 2 Rp197.500
21-5 37735-73R00-ZKB SENSOR ASSY,PARK (RED) 2 Rp197.500
21-1 37735-73R00-ZQZ SENSOR ASSY,PARK (WHITE) 2 Rp192.500
21-2 37735-73R00-Z2S SENSOR ASSY,PARK (SILVER) 2 Rp192.500
21-3 37735-73R00-ZYZ SENSOR ASSY,PARK (GRAY) 2 Rp197.500
21-7 37735-73R00-ZZA SENSOR ASSY,PARK (BROWN) 2 Rp197.500
21-6 37735-73R00-ZLL SENSOR ASSY,PARK (RED) 2 Rp197.500
21-4 37735-73R00-ZBD SENSOR ASSY,PARK (BLACK) 2 Rp192.500
21-1 37735-73R00-ZQZ SENSOR ASSY,PARK (WHITE) 2 Rp192.500
22-2 37737-73R00-Z2S BEZEL,PARK SNSR (SILVER) 2 Rp76.500
22-7 37737-73R00-ZZA BEZEL,PARK SNSR (BROWN) 2 Rp78.000
22-6 37737-73R00-ZLL BEZEL,PARK SNSR (RED) 2 Rp78.000
22-5 37737-73R00-ZKB BEZEL,PARK SNSR (RED) 2 Rp78.000
22-4 37737-73R00-ZBD BEZEL,PARK SNSR (BLACK) 2 Rp76.500
22-3 37737-73R00-ZYZ BEZEL,PARK SNSR (GRAY) 2 Rp76.500
22-1 37737-73R00-ZQZ BEZEL,PARK SNSR (WHITE) 2 Rp76.500
23 71851M70F00-000 NUT 2 Rp4.000
24 03141M0612A-000
SUB: 03141-0612A-000		 SCREW 2 Rp4.500
25 38590-72M00-000 BUZZER ASSY,KLS 1 Rp441.500

*Harga dapat berubah sewaktu-waktu tanpa pemberitahuan terlebih dahulu.
