FIG. 18 MAGNETO

FIG. 18 MAGNETO
No No. Part Description Qty Price Per Pcs Remarks
1 26211-22J10-000
SUB: 26211B22J00N000		 SHAFT, KICK STARTER 1 Rp77.500
2 26221-22J00-000
SUB: 26221B22J00N000		 GUIDE, KICK SHAFT SPRING 1 Rp15.500
3 26231-22J00-000
SUB: 26231B22J00N000		 STARTER, KICK 1 Rp51.000
4 26232-22J00-000
SUB: 26232B22J00N000		 GUIDE, KICK STARTER 1 Rp7.500
5 26233-22J00-000
SUB: 26233B22J00N000		 STOPPER, KICK STARTER 1 Rp6.500
6 26241-22J00-000
SUB: 26241B22J00N000		 GEAR, KICK STARTER DRIVE (NT:21) 1 Rp91.500
7 09283-16008-000
SUB: 09283B16008N000		 OIL SEAL 1 Rp9.500
8 09440-30007-000
SUB: 09440B30007N000		 SPRING 1 Rp3.000
9 26212-22J00-000
SUB: 26212B22J00N000		 GUIDE, SHAFT RETURN SPRING 1 Rp9.000
10 01500-0820A-000
SUB: 01500B0820AN000		 BOLT 1 Rp5.500
11 08211-16241-000
SUB: 08211B16241N000		 WASHER 1 Rp4.500
12 08211-15321-000
SUB: 08211B15321N000		 WASHER 1 Rp10.500
13 26300-22J00-000
SUB: 26300B22J00N000		 LEVER ASSY, KICK STARTER 1 Rp75.000
14 26314-22J00-000
SUB: 26314B22J00N000		 BOLT 1 Rp8.000

*Harga dapat berubah sewaktu-waktu tanpa pemberitahuan terlebih dahulu.
