Electrical - Suzuki Spare Part

Ubah pencarian

Atau cari dengan

Preview Engine Transmission Electrical Suspension Body

AUDIO(W/TUNER)

No	No. Part	Description	Qty	Price Per Pcs	Remarks
1	990H0-990AE-037	HEAD UNIT TOUCH SCREEN 6.8R :K10B	0	Rp3.957.500	K10B
2	39113M69R00-000	.CAP, TUNER	1	Rp129.500
3	39321M62S00-000	BRACKET, TUNER RH	1	Rp28.500
4	39322M62S00-000	BRACKET, TUNER LH	1	Rp28.500
5	73821M62S00-5PK	GARNISH, I/P CTR (BLACK)	1	Rp132.000
6	09409M08344-000	.CLIP	4	Rp4.500
7	09148M05L04-000	NUT	2	Rp5.000
8	02142-0508A-000	SCREW	4	Rp3.500
9	03541-0516A-000	SCREW	2	Rp3.500
10	34955M54G10-000	BUSH, RADIO BRKT	2	Rp6.500
11	34955M79M01-000	BUSH, TUNER BRACKET	2	Rp4.000
12	37275-75J00-000	CAP, USB HOLE R :K10B	1	Rp11.000	K10B
13	39251M69R10-000	ROD, ANTENNA	1	Rp130.000
14	39253M76M01-000	BASE, ANTENNA	1	Rp221.000
15	39270M62S00-000	FEEDER, I/P R :RHD	1	Rp188.000	RHD
16	39271M62S00-000	FEEDER, ROOF	1	Rp175.000
17	39102M62S00-000	SPEAKER ASSY	2	Rp188.000
18-1	3A102M77S13-0CE SUB: 3A102M77S11-0CE	UNIT ASSY, DISPLAY AUDIO R :K10C:9kHz (BLACK)	1	Rp18.950.000	K10C:9kHz
19	39105M77S00-5PK	SOCKET, USB (BLACK) R :K10C	1	Rp49.000	K10C
20	39106M62S10-000	CABLE, USB R :K10C	1	Rp372.500	K10C
21	39813M69R00-000	MIC ASSY, HANDS FREE R :K10C	1	Rp353.500	K10C
22	39814M69R01-6GS	COVER, MIC FRONT (GRAY) R :K10C	1	Rp11.500	K10C
23	39950M62SB0-000	ANTENNA ASSY, GPS R :K10C	1	Rp339.500	K10C
24	03541-0516A-000	SCREW R :K10C	1	Rp3.500	K10C
