S-Presso MC

Preview Engine Transmission Electrical Suspension Body
< KEMBALI KE THUMBNAIL ENGINE ELECTRICALSTARTING MOTOR(K10B)STARTING MOTOR(K10C)GENERATOR(K10B)GENERATOR(K10C)BATTERYSPEEDOMETERHEAD LAMPREAR LAMPROOM LAMPWIRING HARNESSELECTRICAL CONTROL (RHD)LOCK SETFRONT WINDOW WIPER (RHD)WINDOW WASHERAUDIO(N/TUNER)AUDIO(W/TUNER)

AUDIO(N/TUNER)

AUDIO(N/TUNER)
No No. Part Description Qty Price Per Pcs Remarks
1 73821M62S20-5PK GARNISH, I/P CTR (BLACK) 1 Rp141.000
2 09409M08344-000 .CLIP 4 Rp4.500
3 34955M54G10-000 BUSH, RADIO BRKT 2 Rp6.500
4 34955M79M01-000 BUSH, TUNER BRACKET 2 Rp4.000
5 39161M83K01-000 COVER, RADIO HOLE 1 Rp18.000
6 39182M66R00-000 POCKET, TUNER 1 Rp56.500
7 39321M62S10-000 BRACKET, TUNER 1 Rp34.000
8 09148M05L04-000 NUT 2 Rp5.000
9 03241M0512A-000 SCREW 4 Rp4.000
10 03541-0516A-000 SCREW 2 Rp3.500
11 37275-75J00-000 CAP, USB HOLE R :K10B 1 Rp11.000 K10B
12 39102M62S00-000 SPEAKER ASSY 2 Rp188.000
13 39251M69R10-000 ROD, ANTENNA 1 Rp130.000
14 39253M76M01-000 BASE, ANTENNA 1 Rp221.000
15 39270M62S00-000 FEEDER, I/P R :RHD 1 Rp188.000 RHD
16 39271M62S00-000 FEEDER, ROOF 1 Rp175.000
17 39105M77S00-5PK SOCKET, USB (BLACK) 1 Rp49.000
18 39106M62S10-000 CABLE, USB 1 Rp372.500

*Harga dapat berubah sewaktu-waktu tanpa pemberitahuan terlebih dahulu.
