Preview Engine Transmission Electrical Suspension Body

No	No. Part	Description	Qty	Price Per Pcs
1	15897-57L00-000	CLAMP,FUEL PIPE	2	Rp19.500
2	28101-52S00-000	LEVER S/ASSY,GEAR SHIFT CONT	1	Rp468.000
3	28131-52S00-000	CUSHION,GR SHF CONT	4	Rp7.000
4	28133-52S00-000	SPACER,GR SHF CONT CUSHION	4	Rp9.500
5	28113-52S00-5PK	KNOB,GEAR SHIFT CONTROL LEVER	1	Rp69.000
7	28130-52S00-5PK	BOOT,SHIFT LEVER (BLACK)	1	Rp87.500
8	28226-52S00-000	BRACKET,GR SHF CABLE CLAMP FR	1	Rp19.500
9	28226-52S20-000	BRACKET,GR SHF CABLE CLAMP RR	1	Rp18.500
10	28300-52S00-000	CABLE ASSY,GR SHF & SLT CONT	1	Rp1.012.500
11	28341-52S00-000	PLATE,GR SHF CABLE RR	1	Rp92.000
12	28341-52S00-000	PLATE,GR SHF CABLE FR	1	Rp92.000
13	28390-52S00-000	BRACKET,T/M CONT CABLE	1	Rp139.000
14	29365-73J00-000	CLIP,GEAR CONT CABLE NO.2	2	Rp32.500
15	09160-08054-000	WASHER (8.5X20X1.6)	1	Rp10.500
16	09160-08151-000	WASHER (8.5X26X1.6)	4	Rp16.500
17	09385-08007-000	CLIP (L:19)	1	Rp16.500
18	DISCONTINUE SUB: 01550-0816C-000	BOLT	3	-
19	02162-0616A-000	SCREW (6X16)	5	Rp3.000
20	08316-1008A-000	NUT	4	Rp3.500
