FIG. 100 SEAT BELT (TYPE 2)

FIG. 100 SEAT BELT (TYPE 2)

No	No. Part	Description	Qty	Price Per Pcs	Remarks
1	84910-67LA0-000 SUB: 84910B67LA0N000	BUCKLE ASSY, FRONT BELT RH	1	Rp83.500
2	84920-67LB1-BHE SUB: 84920-67LB0-BHE	TONGUE ASSY, FRONT BELT RH (GRAY/BLACK)	1	Rp283.500
3	84910-67LA0-000 SUB: 84910B67LA0N000	BUCKLE ASSY, FRONT BELT LH	1	Rp83.500
4	84940-67LB1-BHE SUB: 84940-67LB0-BHE	TONGUE ASSY, FRONT BELT LH (GRAY/BLACK)	1	Rp283.500
5	09117M11002-000	BOLT (11X20)	2	Rp19.000
6	09103M11002-000 SUB: 09103-11002-000	BOLT (11X20)	2	Rp7.500
7	01550-0612B-000	SCREW	2	Rp16.500
8	DISCONTINUE SUB: 84950-67LB0-000	BUCKLE ASSY, REAR	2	-
9	84960-67LB1-BHE SUB: 84960-67LB0-BHE	TONGUE ASSY, REAR (GRAY/BLACK)	2	Rp294.000
10	84975-67LB0-000	BUCKLE ASSY, REAR BELT CENTER	1	Rp56.500
11	DISCONTINUE SUB: 84985-67LB0-5PK	TONGUE ASSY, REAR BELT CENTER (BLACK)	1	-
12	84996-65DA0-000	CAP, SHOULDER ADJUSTER	2	Rp49.000
13	09103M11002-000 SUB: 09103-11002-000	BOLT (11X20)	8	Rp7.500
14	01550-0612B-000	SCREW	2	Rp16.500

*Harga dapat berubah sewaktu-waktu tanpa pemberitahuan terlebih dahulu.
