FIG. 95 BACK DOOR PANEL

No	No. Part	Description	Qty	Price Per Pcs	Remarks
1	69100-67L21-000 SUB: 69100B67L20N000	PANEL ASSY, BACK DOOR	1	Rp2.065.000
2	69510-58J10-000 SUB: 69510B58J10N000	HINGE, BACK DOOR	2	Rp63.000
3	69571M76G00-000	•PACKING	2	Rp6.500
4	DISCONTINUE SUB: 01550B0612AN000	BOLT	4	-
5	08361-2508A-000	NUT	2	Rp16.500
6-1	81850M67L01-000 SUB: 81850M67L00-000	BALANCER, BACK DOOR RH	1	Rp324.500	GA,GL,GX,GS (UP TO 2015-2)
6-2	81850M67L01-000 SUB: 81850-67LA0-000	BALANCER, BACK DOOR RH	1	Rp324.500	GS (FROM 2015-3)
7-1	81860M67L00-000	BALANCER, BACK DOOR LH	1	Rp324.500	GA,GL,GX,GS (UP TO 2015-2)
7-2	81860-67LA0-000	BALANCER, BACK DOOR LH	1	-	GS (FROM 2015-3)
8	81871-67LA0-000	BALLSTUD, BACK DOOR BALANCER	2	-	GS (FROM 2015-3)
9	01551-0816C-000	BOLT	4	Rp13.500
10	82683M60B00-000	CUSHION, BACK DOOR SIDE	2	Rp8.500
11	09321-10041-000	CUSHION	2	Rp21.000
12	83770-67L00-5PK SUB: 83770B67L00N5PK	TRIM, BACK DOOR (BLACK)	1	Rp93.500
13	09409-08308-5ES	CLIP (BLACK)	9	Rp15.000
14	84570-67LA0-000 SUB: 84570B67LA0N000	GLASS, BACK DOOR WINDOW	1	Rp576.500
15	84513-76F00-000	•MALE, GLASS FASTENER NO.2	2	Rp38.500
16	84572-74G00-000	•MALE, GLASS FASTENER NO.1	2	Rp42.500
17	84515-65D00-000	FEMALE, GLASS FASTENER NO.2	4	Rp45.500
18	84681-67LA0-000 SUB: 84681B67LA0N000	WEATHERSTRIP, BACK DOOR OPNG	1	Rp198.000
19	44281-29C00-000 SUB: 63191-25C00-000	CUSHION	2	Rp6.000
20	83916-67L00-000 SUB: 83916B67L00N000	COVER, BACK DOOR SEALING	1	Rp26.500
21-1	83940-67LA0-5PK SUB: 83940B67LA0N5PK	GARNISH, BACK DOOR LICENSE (BLACK)	1	Rp267.000	GA
21-2	83940-67LC0-0PG	GARNISH, BACK DOOR LICENSE (CHROME)	1	Rp1.403.000	GL,GX,GS
22	71812-78F00-000 SUB: 71812B78F00N000	•CLIP, DOOR LICENSE GARNISH	2	Rp9.000
23	09250M20031-000 SUB: 09250M20023-000	CAP (OD:25.8)	1	Rp4.500
24	08316-1006A-000 SUB: 08316B1006AN000	NUT	4	Rp2.000
25	09148-05035-000	NUT	2	Rp18.500
