KARIMUN WAGON R TIPE 1 & 2

Preview Engine Transmission Electrical Suspension Body

< KEMBALI KE THUMBNAIL FIG. 64 FRONT HOOD PANEL (GA,GL,GX)FIG. 64A FRONT HOOD PANEL (GS)FIG. 65 FRONT FENDER PANEL (GA,GL,GX)FIG. 66 FRONT BODY PANEL FIG. 67 FLOOR PANEL FIG. 68 SIDE BODY PANEL FIG. 69 ROOF PANEL FIG. 70 FRONT BUMPER (GA,GL,GX)FIG. 70A FRONT BUMPER (GS)FIG. 71 REAR BUMPER (GA,GL,GX)FIG. 71A REAR BUMPER (GS)FIG. 72 INSTRUMENT PANEL FIG. 73 VENTILATOR FIG. 74 COOLING UNIT FIG. 75 HEATER CONTROL FIG. 76 CONSOLE BOX FIG. 77 FLOOR CARPET (GA)FIG. 77A FLOOR CARPET (GL,GX,GS)FIG. 78 INTERIOR TRIM FIG. 79 COVER/CAP FIG. 80 FUEL LID OPENER (GA)FIG. 81 FUEL LID OPENER (GL,GX,GS)FIG. 82 ROOF LINING FIG. 83 ROOF MOLDING (GA,GS)FIG. 84 ROOF MOLDING (GL,GX)FIG. 85 EMBLEM (GA,GL,GX)FIG. 86 EMBLEM (GS)FIG. 87 WINDSHIELD FIG. 88 FRONT DOOR PANEL FIG. 89 FRONT DOOR REGULATOR (GA)FIG. 90 FRONT DOOR REGULATOR (GL,GX,GS)FIG. 91 FRONT DOOR LOCK FIG. 92 REAR DOOR PANEL FIG. 93 REAR DOOR REGULATOR FIG. 94 REAR DOOR LOCK FIG. 95 BACK DOOR PANEL FIG. 96 BACK DOOR LOCK FIG. 97 MIRROR/SUNVISOR (GA)FIG. 98 MIRROR/SUNVISOR (GL,GX,GS)FIG. 99 SEAT BELT (TYPE 1)FIG. 100 SEAT BELT (TYPE 2)FIG. 101 FRONT RH SEAT FIG. 102 FRONT LH SEAT (GA,GL)FIG. 103 FRONT LH SEAT (GX,GS)FIG. 104 REAR SEAT FIG. 105 FUEL TANK FIG. 106 TOOL FIG. 107 AIR CONDITIONER FIG. 108 COMPRESSOR

FIG. 96 BACK DOOR LOCK

FIG. 96 BACK DOOR LOCK

No	No. Part	Description	Qty	Price Per Pcs	Remarks
1	82510M67L00-000	LATCH ASSY, BACK DOOR	1	Rp247.500	GA,GL
2	82510M67L10-000	LATCH ASSY, BACK DOOR	1	Rp295.000	GX,GS
3	02162-0616A-000	SCREW	3	Rp3.000
4	82291-81A00-000 SUB: 82291B81A00N000	RETAINER, BACK DOOR CYLINDER	1	Rp48.500
5	82500-67880-000 SUB: 82500B67880N000	CYLINDER, BACK DOOR LOCK	1	Rp840.500
6	82650M83E00-000 SUB: 82650M79J00-000	STRIKER, BACK DOOR LATCH	1	Rp54.000	GA,GL
7	82650M75J00-000	STRIKER, BACK DOOR LATCH	1	Rp61.500	GX,GS
8	09137-08014-000 SUB: 09137-08004-000	SCREW (8X18)	2	Rp23.000

*Harga dapat berubah sewaktu-waktu tanpa pemberitahuan terlebih dahulu.
