FIG. 66 FRONT BODY PANEL

No	No. Part	Description	Qty	Price Per Pcs	Remarks
1	58310-67LH0-000 SUB: 58310B67LG0N000	PANEL, FENDER APRON RH	1	Rp1.414.000
2	58315-67L00-000 SUB: 58315B67L00N000	BRACKET, FR FENDER LWR RH	1	Rp14.000
3-2	58410-67LK0-000	PANEL, FENDER APRON LH	1	Rp201.500	TYPE 2
3-1	DISCONTINUE SUB: 58410B67LG0N000	PANEL, FENDER APRON LH	1	-	TYPE 1
4	58415-67L00-000 SUB: 58415B67L00N000	BRACKET, FR FENDER LWR LH	1	Rp14.000
5	58600-67LG1-000 SUB: 58600-67LG0-000	MEMBER, FRONT SIDE RH	1	Rp956.000
6	58610-67LG1-000 SUB: 58610-67LG0-000	•MEMBER, APRON SIDE RH	1	Rp263.000
7	58630-67LG1-000 SUB: 58630-67LG0-000	•PANEL, APRN SIDE MBR OTR RH	1	Rp216.500
8	58650-67L10-000 SUB: 58650B67L10N000	MEMBER, FLOOR SIDE RH	1	Rp118.500
9	58700-67LG1-000 SUB: 58700-67LG0-000	MEMBER, FRONT SIDE LH	1	Rp956.000
10	58710-67LG1-000 SUB: 58710-67LG0-000	•MEMBER, APRON SIDE LH	1	Rp263.000
11	58730-67LG1-000 SUB: 58730-67LG0-000	•PANEL, APRN SIDE MBR OTR LH	1	Rp221.500
12	58751-67L00-000 SUB: 58751B67L00N000	MEMBER, FLOOR SIDE LH	1	Rp97.000
13-1	59100-67L40-000 SUB: 59100B67L40N000	PANEL, DASH	1	Rp2.476.500	TYPE 1
13-2	59100-67L50-000	PANEL, DASH	1	Rp1.281.500	TYPE 2:5MT
13-3	59100-67L30-000	PANEL, DASH	1	Rp1.291.500	TYPE 2:5AGS
14	59210-67L10-000 SUB: 59210B67L10N000	PANEL, DASH LOWER SIDE RH	1	Rp130.000
15	59220-67L10-000 SUB: 59220B67L10N000	PANEL, DASH LOWER SIDE LH	1	Rp130.000
16	59230-67L00-000 SUB: 59230B67L00N000	PANEL, DASH SIDE RH	1	Rp673.500
17	59234-67L00-000 SUB: 59234B67L00N000	•PANEL, DASH SIDE FR RH	1	Rp60.000
18	59280-67L20-000 SUB: 59280B67L20N000	PANEL, DASH SIDE LH	1	Rp685.000
19	59284-67L00-000 SUB: 59284B67L00N000	•PANEL, DASH SIDE FR LH	1	Rp60.000
20	59711-67LG0-000 SUB: 59711B67LG0N000	PANEL, COWLING TOP	1	Rp1.325.500
21	59712-81J00-000 SUB: 59712B81J00N000	BRACKET, I/P UPPER	3	Rp1.135.000
22-1	59721-67LG0-000 SUB: 59721B67LG0N000	PANEL, COWLING FR	1	Rp550.500	TYPE 1
22-2	59721-67LK0-000	PANEL, COWLING FR	1	Rp176.000	TYPE 2
23	59722-70K00-000 SUB: 59722B70K00N000	BRACKET, WIPER UNIT CTR	1	Rp333.500
24	59723-67LG0-000	BRACKET, WIPER LINK SIDE	1	Rp14.500
25-1	59730-67L00-000 SUB: 59730B67L00N000	PANEL, COWL SIDE RH	1	Rp1.145.000	GA,GL,GX
25-2	59730M67LD0-000	PANEL, COWL SIDE RH	1	Rp145.000	GS
26-1	59732-67L00-000 SUB: 59732B67L00N000	•BRACKET, FRONT FENDER RH	1	Rp1.025.500	GA,GL,GX
26-2	59732M67LD0-000	•BRACKET, FRONT FENDER RH	1	Rp17.500	GS
27-1	59780-67LG0-000 SUB: 59780B67LG0N000	PANEL, COWL SIDE LH	1	Rp1.135.000	GA,GL,GX
27-2	59780M67LD0-000	PANEL, COWL SIDE LH	1	Rp145.000	GS
28-1	59732-67L00-000 SUB: 59732B67L00N000	•BRACKET, FRONT FENDER LH	1	Rp1.025.500	GA,GL,GX
28-2	59782M67LD0-000	•BRACKET, FRONT FENDER LH	1	Rp17.500	GS
29	72381-67L00-000 SUB: 72381B67L00N000	BRACKET, RADIATOR LOWER	2	Rp27.000
30	01551-0816C-000	BOLT	4	Rp13.500
31	63461-80000-000	BOLT, BATTERY	2	Rp51.500
32	72511-78000-000 SUB: 72511B78000N000	BAND, BATTERY	1	Rp9.000
33-1	72520-67LG0-000 SUB: 72520B67LG0N000	TRAY, BATTERY	1	Rp122.000	5MT
33-2	72520-67LK0-000	TRAY, BATTERY	1	Rp200.000	5AGS
34	DISCONTINUE SUB: 01550B0612AN000	BOLT	3	-
35	08316-1005A-000 SUB: 08316B1005AN000	NUT	2	Rp2.500
36	08316-1006A-000 SUB: 08316B1006AN000	NUT	1	Rp2.000
