FIG. 64A FRONT HOOD PANEL (GS)

No	No. Part	Description	Qty	Price Per Pcs
1	57300M67LD0-000	PANEL, FRONT HOOD	1	Rp2.149.000
2	57410-67L00-000 SUB: 57410-67LG0-000	HINGE, FRONT HOOD RH	1	Rp24.500
3	57420-67L00-000 SUB: 57420-67LG0-000	HINGE, FRONT HOOD LH	1	Rp24.500
4	DISCONTINUE SUB: 01550B0612AN000	BOLT	8	-
5	58110M67LD0-000	BRACE, LAMP SUPPORT RH	1	Rp121.000
6	58121M67LD0-000	BRACE, LAMP SUPPORT LH	1	Rp121.000
7	58210-67LG0-000 SUB: 58210B67L10N000	CROSSMEMBER, FRONT LOWER	1	Rp323.000
8	58230M67LD0-000	MEMBER, HOOD LOCK	1	Rp224.500
9	58240M67LD0-000	BRACE, HOOD LOCK	1	Rp134.000
10	58251M67LD0-000	MEMBER, LAMP SUPPORT RH	1	Rp130.000
11	58261M67LD0-000	MEMBER, LAMP SUPPORT LH	1	Rp130.000
12	58271M67LD0-000	BRACKET,HOOD CUSHION	2	Rp15.000
13	DISCONTINUE SUB: 01550B0612AN000	BOLT	4	-
14	DISCONTINUE SUB: 01550B0612AN000	BOLT	2	-
15	72310-67L00-000 SUB: 72310B67L00N000	STAY, FRONT HOOD	1	Rp29.000
16	72312-67LG0-000 SUB: 72312B67LG0N000	HOLDER, FRONT HOOD STAY	1	Rp7.500
17	72331-67LG0-5PK SUB: 72331B67LG0N5PK	GARNISH, COWL TOP CTR (BLACK)	1	Rp590.000
18	72341-67LG0-5PK SUB: 72341B67LG0N5PK	GARNISH, COWL TOP SIDE RH (BLACK)	1	Rp216.000
19	72342-67LG0-5PK SUB: 72342B67LG0N5PK	GARNISH, COWL TOP SIDE LH (BLACK)	1	Rp216.000
20	72362-54M00-000	SEAL, HOOD REAR	1	Rp315.500
21	72372-63J00-000 SUB: 72372B63J00N000	CUSHION	2	Rp8.000
22	09209M09L02-000 SUB: 09209M09007-000	LINKAGE	1	Rp4.500
23	09321-10023-000 SUB: 09321B10023N000	CUSHION	3	Rp6.000
24	09409M07L02-5PK SUB: 09409M07308-5PK	CLIP (BLACK)	4	Rp7.500
25	09409M07L02-5PK SUB: 09409M07308-5PK	CLIP (BLACK)	2	Rp7.500
26	09403M04401-000	CLAMP	3	Rp4.500
27	82110M67LD1-000 SUB: 82110M67LD0-000	LATCH, HOOD	1	Rp166.500
28	82160-67LL0-000	CABLE, HOOD LATCH RELEASE	1	Rp64.500
29	82191-50E00-000	•GROMMET, LATCH RELEASE CABLE	1	Rp41.500
30	01550-0616A-000 SUB: 01550B0616AN000	BOLT	3	Rp3.500
