KARIMUN WAGON R TIPE 1 & 2

Preview Engine Transmission Electrical Suspension Body

< KEMBALI KE THUMBNAIL FIG. 64 FRONT HOOD PANEL (GA,GL,GX)FIG. 64A FRONT HOOD PANEL (GS)FIG. 65 FRONT FENDER PANEL (GA,GL,GX)FIG. 66 FRONT BODY PANEL FIG. 67 FLOOR PANEL FIG. 68 SIDE BODY PANEL FIG. 69 ROOF PANEL FIG. 70 FRONT BUMPER (GA,GL,GX)FIG. 70A FRONT BUMPER (GS)FIG. 71 REAR BUMPER (GA,GL,GX)FIG. 71A REAR BUMPER (GS)FIG. 72 INSTRUMENT PANEL FIG. 73 VENTILATOR FIG. 74 COOLING UNIT FIG. 75 HEATER CONTROL FIG. 76 CONSOLE BOX FIG. 77 FLOOR CARPET (GA)FIG. 77A FLOOR CARPET (GL,GX,GS)FIG. 78 INTERIOR TRIM FIG. 79 COVER/CAP FIG. 80 FUEL LID OPENER (GA)FIG. 81 FUEL LID OPENER (GL,GX,GS)FIG. 82 ROOF LINING FIG. 83 ROOF MOLDING (GA,GS)FIG. 84 ROOF MOLDING (GL,GX)FIG. 85 EMBLEM (GA,GL,GX)FIG. 86 EMBLEM (GS)FIG. 87 WINDSHIELD FIG. 88 FRONT DOOR PANEL FIG. 89 FRONT DOOR REGULATOR (GA)FIG. 90 FRONT DOOR REGULATOR (GL,GX,GS)FIG. 91 FRONT DOOR LOCK FIG. 92 REAR DOOR PANEL FIG. 93 REAR DOOR REGULATOR FIG. 94 REAR DOOR LOCK FIG. 95 BACK DOOR PANEL FIG. 96 BACK DOOR LOCK FIG. 97 MIRROR/SUNVISOR (GA)FIG. 98 MIRROR/SUNVISOR (GL,GX,GS)FIG. 99 SEAT BELT (TYPE 1)FIG. 100 SEAT BELT (TYPE 2)FIG. 101 FRONT RH SEAT FIG. 102 FRONT LH SEAT (GA,GL)FIG. 103 FRONT LH SEAT (GX,GS)FIG. 104 REAR SEAT FIG. 105 FUEL TANK FIG. 106 TOOL FIG. 107 AIR CONDITIONER FIG. 108 COMPRESSOR

FIG. 77A FLOOR CARPET (GL,GX,GS)

FIG. 77A FLOOR CARPET (GL,GX,GS)

No	No. Part	Description	Qty	Price Per Pcs	Remarks
1	75110-67L01-S01 SUB: 75110B67L00NS01	CARPET, FLOOR (GRAY)	1	Rp1.118.500
2	75139M70F00-5PK	CLIP, FLOOR CARPET (BLACK)	1	Rp6.500
3	09148-05042-000	CLIP	3	Rp17.500
4	DISCONTINUE SUB: 75220B67L50N000	SILENCER, DASH PANEL	1	-
5	99611-60A01-000	SHEET, SILENCER (800X1000X3)	4	Rp1.210.000
6	75440-67L10-S01 SUB: 75440B67L10NS01	CARPET, LUGGAGE FL (GRAY)	1	Rp486.500
7	75451-67L50-000 SUB: 75451B67L50N000	BOX, LUGGAGE FLR RH	1	Rp111.500
8	75452-67L50-000 SUB: 75452B67L50N000	BOX, LUGGAGE FLR LH	1	Rp99.000
9	75463M67L00-000	SCREW, SPARE TIRE	1	Rp14.000
10	75531-67L50-000 SUB: 75531B67L50N000	PAD, MAIN FLOOR UPR RR RH	1	Rp137.500
11	75541-67L50-000 SUB: 75541B67L50N000	PAD, MAIN FLOOR UPR RR LH	1	Rp137.500
12	09409-08321-5ES	CLIP (BLACK)	4	Rp18.500

*Harga dapat berubah sewaktu-waktu tanpa pemberitahuan terlebih dahulu.
