KARIMUN WAGON R TIPE 1 & 2

Preview Engine Transmission Electrical Suspension Body

< KEMBALI KE THUMBNAIL FIG. 64 FRONT HOOD PANEL (GA,GL,GX)FIG. 64A FRONT HOOD PANEL (GS)FIG. 65 FRONT FENDER PANEL (GA,GL,GX)FIG. 66 FRONT BODY PANEL FIG. 67 FLOOR PANEL FIG. 68 SIDE BODY PANEL FIG. 69 ROOF PANEL FIG. 70 FRONT BUMPER (GA,GL,GX)FIG. 70A FRONT BUMPER (GS)FIG. 71 REAR BUMPER (GA,GL,GX)FIG. 71A REAR BUMPER (GS)FIG. 72 INSTRUMENT PANEL FIG. 73 VENTILATOR FIG. 74 COOLING UNIT FIG. 75 HEATER CONTROL FIG. 76 CONSOLE BOX FIG. 77 FLOOR CARPET (GA)FIG. 77A FLOOR CARPET (GL,GX,GS)FIG. 78 INTERIOR TRIM FIG. 79 COVER/CAP FIG. 80 FUEL LID OPENER (GA)FIG. 81 FUEL LID OPENER (GL,GX,GS)FIG. 82 ROOF LINING FIG. 83 ROOF MOLDING (GA,GS)FIG. 84 ROOF MOLDING (GL,GX)FIG. 85 EMBLEM (GA,GL,GX)FIG. 86 EMBLEM (GS)FIG. 87 WINDSHIELD FIG. 88 FRONT DOOR PANEL FIG. 89 FRONT DOOR REGULATOR (GA)FIG. 90 FRONT DOOR REGULATOR (GL,GX,GS)FIG. 91 FRONT DOOR LOCK FIG. 92 REAR DOOR PANEL FIG. 93 REAR DOOR REGULATOR FIG. 94 REAR DOOR LOCK FIG. 95 BACK DOOR PANEL FIG. 96 BACK DOOR LOCK FIG. 97 MIRROR/SUNVISOR (GA)FIG. 98 MIRROR/SUNVISOR (GL,GX,GS)FIG. 99 SEAT BELT (TYPE 1)FIG. 100 SEAT BELT (TYPE 2)FIG. 101 FRONT RH SEAT FIG. 102 FRONT LH SEAT (GA,GL)FIG. 103 FRONT LH SEAT (GX,GS)FIG. 104 REAR SEAT FIG. 105 FUEL TANK FIG. 106 TOOL FIG. 107 AIR CONDITIONER FIG. 108 COMPRESSOR

FIG. 71 REAR BUMPER (GA,GL,GX)

FIG. 71 REAR BUMPER (GA,GL,GX)

No	No. Part	Description	Qty	Price Per Pcs	Remarks
1-1	71811-67LG0-5PK SUB: 71811B67LG0N5PK	BUMPER, REAR (BLACK)	1	Rp906.000	GA
1-2	71811-67LG0-799 SUB: 71811B67LG0N799	BUMPER, REAR (PAINT TO MATCH)	1	Rp778.500	GL,GX
2	71812-67L00-000 SUB: 71812B67L00N000	HOLDER, RR BUMPER SIDE RH	1	Rp18.500
3	71813-67L00-000 SUB: 71813B67L00N000	HOLDER, RR BUMPER SIDE LH	1	Rp18.500
4	09409-08327-000	CLIP	6	Rp15.000
5	01550-0616A-000 SUB: 01550B0616AN000	SCREW	3	Rp3.500
6	03541-0512B-000 SUB: 03541B0512BN000	SCREW	4	Rp4.000

*Harga dapat berubah sewaktu-waktu tanpa pemberitahuan terlebih dahulu.
