Preview Engine Transmission Electrical Suspension Body

No	No. Part	Description	Qty	Price Per Pcs
1	31100-20G00-000 SUB: 31100B20G00N000	MOTOR ASSY, STARTING	1	Rp532.500
2	DISCONTINUE SUB: 31310B20G00N000	.AMATURE	1	-
3	31130-20G00-000 SUB: 31130B20G00N000	.HOLDER SET, BRUSH	1	Rp34.000
4	31131-20G00-000 SUB: 31131B20G00N000	.BRUSH SET	1	Rp47.500
5	31135-19D00-000 SUB: 31135B19D00N000	..SPRING	2	Rp4.500
6	DISCONTINUE SUB: 31143B49040N000	..O RING	1	-
7	31151-20G00-000 SUB: 31151B20G00N000	.HOUSING SET	1	Rp140.500
8	31156-98E00-000 SUB: 31156B98E00N000	..O RING	1	Rp3.000
9	31170-19B10-000 SUB: 31170B19B10N000	.WASHER SET	1	Rp12.000
10	31264-13E00-000 SUB: 31264B13E00N000	.O RING	2	Rp4.000
11	31280-20G00-000 SUB: 31280B20G00N000	.BOLT SET	2	Rp4.000
12	DISCONTINUE SUB: 31143B49040N000	..O RING	2	-
13	DISCONTINUE SUB: 08316B20G00N000	..NUT SET	1	-
14	01547-0625A-000 SUB: 01547-06253-000	BOLT, STARTING MOTOR	2	Rp6.500
15	DISCONTINUE SUB: 08361B35066N000	NUT	1	-
