| 1 |
37485M55K00-000 |
BODY ASSY, CANCEL CAM & HORN |
1 |
Rp218.000 |
STD | |
| 2 |
37480-62J20-000 |
CABLE ASSY, CONTACT COIL |
1 |
Rp1.548.000 |
DX | |
| 3 |
37210-73HB1-000
SUB: 37210-58J00-000 |
SWITCH ASSY, LIGHTING & TURN |
1 |
Rp286.000 |
| |
| 4 |
37310-62J71-000
SUB: 37310-62J70-000 |
SWITCH ASSY, WIPER & WASHER |
1 |
Rp1.421.000 |
| |
| 5 |
37740-81K00-000
SUB: 37740B75H10N000 |
SWITCH ASSY, STOP LAMP |
1 |
Rp77.500 |
| |
| 6 |
37670-58J10-000
SUB: 37670B58J10N000 |
SWITCH ASSY, DOOR |
4 |
Rp107.500 |
| |
| 7 |
37270-62J00-000 |
SWITCH ASSY, FR FOG |
1 |
Rp375.000 |
W/FRONT FOG LAMP | |
| 8 |
38860-76F01-000
SUB: 38860B76F01N000 |
RELAY, FR FOG |
1 |
Rp47.000 |
W/FRONT FOG LAMP | |
| 9 |
37430-62J00-P4Z |
SWITCH ASSY, HAZARD WARNING (GRAY) |
1 |
Rp322.500 |
| |
| 10 |
37285-62J10-000 |
CAP, OPTION SWITCH HOLE |
0 |
Rp41.500 |
| |
| 11 |
37990-80J00-000 |
SWITCH ASSY, POWER WINDOW MAIN |
1 |
Rp1.732.500 |
| |
| 12 |
37995-62J00-000 |
SWITCH ASSY, POWER WINDOW SUB |
1 |
Rp247.500 |
| |
| 13 |
37995-62J00-000 |
SWITCH ASSY, POWER WINDOW RR |
2 |
Rp247.500 |
| |
| 14-1 |
37950-62J01-000
SUB: 37950-62J00-000 |
SWITCH ASSY, MIRROR |
1 |
Rp274.000 |
STD | |
| 14-2 |
37950-62J11-000
SUB: 37950-62J10-000 |
SWITCH ASSY, MIRROR |
1 |
Rp333.000 |
DX | |
| 15 |
37285-62J00-000 |
CAP, OPTION SWITCH HOLE |
0 |
Rp45.000 |
| |
| 16 |
38860-76F01-000
SUB: 38860B76F01N000 |
RELAY, SHIFT LOCK |
1 |
Rp47.000 |
AT | |
| 17 |
38500-81K00-000
SUB: 38500B81K00N000 |
HORN ASSY, LOW PITCHED |
1 |
Rp89.000 |
| |
| 18 |
38500-81K10-000
SUB: 38500B81K10N000 |
HORN ASSY, HIGH PITCHED |
1 |
Rp103.500 |
| |
| 19 |
09115-08001-000 |
BOLT |
2 |
Rp21.500 |
| |
| 20 |
DISCONTINUE
SUB: 38570B81K00N000 |
BRACKET, HORN |
1 |
- |
| |
| 21 |
09115-06005-000 |
BOLT |
2 |
Rp14.000 |
| |
| 22 |
38610-84F00-000 |
RELAY, TURN SIGNAL & 4 WAY |
1 |
Rp613.000 |
| |
| 23-1 |
DISCONTINUE
SUB: 34600-79J10-000 |
MONITOR ASSY, CLOCK |
1 |
- |
STD | |
| 23-2 |
DISCONTINUE
SUB: 34600-80J02-000 |
MONITOR ASSY, INFORMATION |
1 |
- |
DX | |
| 24 |
09409-08332-000 |
•CLIP |
3 |
Rp18.000 |
| |
| 25 |
95643-58J00-000 |
SENSOR, OUTSIDE TEMPERATURE |
1 |
Rp262.000 |
DX | |
| 26 |
02162-0616B-000 |
SCREW |
2 |
Rp15.500 |
| |
| 27 |
38860-76F01-000
SUB: 38860B76F01N000 |
RELAY, AT |
1 |
Rp47.000 |
AT | |
| 28 |
77151-82000-000
SUB: 77151B82000N000 |
FILM, SIDE BODY OUTER, REAR |
1 |
Rp7.000 |
| |
| 29 |
38910-79J02-000 |
CONTROLLER ASSY, AIR BAG |
1 |
Rp9.992.500 |
DX | |
| 30-1 |
09115-06004-000 |
BOLT (6X16) |
3 |
Rp19.500 |
DX | |
| 30-2 |
DISCONTINUE
SUB: 09129-06006-000 |
BOLT |
3 |
- |
STD | |
| 31 |
38930-80J00-000 |
SENSOR ASSY, FORWARD |
1 |
Rp1.278.000 |
DX | |
| 32 |
09115-06004-000 |
BOLT (6X16) |
1 |
Rp19.500 |
DX | |
| 33 |
38880-80J30-000 |
CONTROLLER ASSY, AT |
1 |
Rp11.131.500 |
AT | |
| 34 |
08316-1006A-000
SUB: 08316B1006AN000 |
NUT |
2 |
Rp2.000 |
AT | |
| 35 |
DISCONTINUE
SUB: 39400-59J10-000 |
LIGHTER ASSY, CIGARETTE |
1 |
- |
| |
| 36 |
DISCONTINUE
SUB: 84761-50X50-000 |
SEAL (140X190) |
1 |
- |
| |
| 37 |
DISCONTINUE
SUB: 37675-55G00-000 |
SWITCH ASSY, TRUNK |
1 |
- |
| |
| 38 |
02142-0508A-000
SUB: 02142B0508AN000 |
SCREW |
2 |
Rp3.500 |
| |
| 39 |
DISCONTINUE
SUB: 38720B79J50N000 |
CONTROLLER ASSY, EPS |
1 |
- |
| |
| 40 |
09115-06005-000 |
BOLT (6X16) |
2 |
Rp14.000 |
| |
| 41 |
DISCONTINUE
SUB: 38721B56K00N000 |
BRACKET, EPS CONTROLLER |
1 |
- |
| |
| 42 |
02162-0508A-000
SUB: 02162B0508AN000 |
SCREW |
2 |
Rp3.500 |
| |
| 43 |
38850-81K00-000 |
CONTROLLER ASSY SPEED CONVERTER |
1 |
Rp3.098.500 |
STD:MT | |
| 44 |
02162-0616A-000 |
BOLT |
1 |
Rp3.000 |
STD:MT | |
