KARIMUN WAGON R TIPE 1 & 2

Preview Engine Transmission Electrical Suspension Body
< KEMBALI KE THUMBNAIL FIG. 28 ENGINE ELECTRICAL (TYPE 1)FIG. 28A ENGINE ELECTRICAL (TYPE 2)FIG. 29 STARTING MOTORFIG. 30 GENERATOR (TYPE 1)FIG. 30A GENERATOR (TYPE 2)FIG. 31 BATTERY (5MT)FIG. 31A BATTERY (5AGS)FIG. 32 SPEEDOMETER (GA)FIG. 34 HEADLAMP (GA,GL,GX)FIG. 34A HEADLAMP (GS)FIG. 35 REAR LAMPFIG. 36 ROOM LAMPFIG. 37 WIRING HARNESS (TYPE 1:(GA,GL,GX))FIG. 37A WIRING HARNESS (TYPE 1:(GS))FIG. 37B WIRING HARNESS (TYPE 2:(GA,GL,GX))FIG. 37C WIRING HARNESS (TYPE 2:(GS))FIG. 38 ENGINE HARNESS BRACKET (5MT)FIG. 38A ENGINE HARNESS BRACKET (5AGS)FIG. 39 ELECTRICAL CONTROL (TYPE 1)FIG. 39A ELECTRICAL CONTROL (TYPE 2)FIG. 40 LOCK SET (GA,GL)FIG. 41 LOCK SET (GX,GS)FIG. 42 FRONT WINDOW WIPERFIG. 43 WINDOW WASHERFIG. 44 AUDIO (GA)FIG. 45 AUDIO (GL)FIG. 46 AUDIO (GX,GS)

FIG. 39 ELECTRICAL CONTROL (TYPE 1)

FIG. 39 ELECTRICAL CONTROL (TYPE 1)
No No. Part Description Qty Price Per Pcs Remarks
1 37485M55K00-000 BODY ASSY, CANCEL CAM & HORN 1 Rp218.000
2 37210-77M00-000
SUB: 37210B77M00N000		 SWITCH ASSY, LIGHTING & TURN 1 Rp277.000
3 37310-50M10-000 SWITCH ASSY, WIPER & WASHER 1 Rp980.500
4 37430M67L00-5PK SWITCH ASSY, HAZARD WARNING (BLACK) 1 Rp148.000
5 37740-81K00-000
SUB: 37740B81K00N000		 SET, STOP LAMP SWITCH 1 Rp77.500
6-1 37670M60M10-000
SUB: 37670M60M00-000		 SWITCH ASSY, DOOR 1 Rp35.000 GA
6-2 37670M60M10-000
SUB: 37670M60M00-000		 SWITCH ASSY, DOOR 4 Rp35.000 GL,GX
6-3 37670M55K01-000 SWITCH ASSY, DOOR 4 - GS
7 DISCONTINUE
SUB: 37671B67L00N000		 CAP, DOOR SWITCH HOLE 3 - GA
8 37990-67L00-000 SWITCH ASSY, POWER WINDOW MAIN 1 Rp1.123.000 GL,GX,GS
9 37995-71L00-000 SWITCH ASSY, POWER WINDOW SUB 1 Rp207.500 GL,GX,GS
10 03541-0410A-000 SCREW 1 Rp11.000 GL,GX,GS
11-1 38500-67L20-000
SUB: 38500B67L20N000		 HORN ASSY, LOW PITCHED 1 Rp90.000 GA,GL,GX
11-2 38500M67LB0-000 HORN ASSY, LOW PITCHED 1 Rp249.000 GS
12 09115-08001-000 BOLT (8X18) 1 Rp21.500
13 38610M75J10-000
SUB: 38610M75J00-000		 RELAY ASSY, TURN & 4 WAY 1 Rp368.000
14-1 38700M67LA0-000 CONTROLLER ASSY, DOOR LOCK 1 Rp542.500 GL
14-2 37190-67L00-000 CONTROLLER ASSY, KEYLESS 1 Rp2.827.500 GX,GS
15 03141-0516B-000
SUB: 03141M0512A-000		 SCREW 1 Rp3.500
16 38720-67L11-000
SUB: 38720B67L10N000		 CONTROLLER ASSY, POWER STRG 1 Rp1.996.500 GL,GX,GS
17 02142-0516A-000
SUB: 02142B0516AN000		 SCREW 2 Rp3.500 GL,GX,GS
18 37275-67L00-000
SUB: 37275B67L00N000		 CAP, CIGAR LIGHTER HOLE 1 Rp11.000 GA,GL
19 39420-76F00-000 BODY, SOCKET 1 Rp103.000 GX,GS
20 39441-67L00-5PK
SUB: 39441B67L00N5PK		 COVER, SOCKET 1 Rp16.500 GX,GS

*Harga dapat berubah sewaktu-waktu tanpa pemberitahuan terlebih dahulu.
