  5. FIG. 37B WIRING HARNESS (TYPE 2:(GA,GL,GX))

KARIMUN WAGON R TIPE 1 & 2

Preview Engine Transmission Electrical Suspension Body
< KEMBALI KE THUMBNAIL FIG. 28 ENGINE ELECTRICAL (TYPE 1)FIG. 28A ENGINE ELECTRICAL (TYPE 2)FIG. 29 STARTING MOTORFIG. 30 GENERATOR (TYPE 1)FIG. 30A GENERATOR (TYPE 2)FIG. 31 BATTERY (5MT)FIG. 31A BATTERY (5AGS)FIG. 32 SPEEDOMETER (GA)FIG. 34 HEADLAMP (GA,GL,GX)FIG. 34A HEADLAMP (GS)FIG. 35 REAR LAMPFIG. 36 ROOM LAMPFIG. 37 WIRING HARNESS (TYPE 1:(GA,GL,GX))FIG. 37A WIRING HARNESS (TYPE 1:(GS))FIG. 37B WIRING HARNESS (TYPE 2:(GA,GL,GX))FIG. 37C WIRING HARNESS (TYPE 2:(GS))FIG. 38 ENGINE HARNESS BRACKET (5MT)FIG. 38A ENGINE HARNESS BRACKET (5AGS)FIG. 39 ELECTRICAL CONTROL (TYPE 1)FIG. 39A ELECTRICAL CONTROL (TYPE 2)FIG. 40 LOCK SET (GA,GL)FIG. 41 LOCK SET (GX,GS)FIG. 42 FRONT WINDOW WIPERFIG. 43 WINDOW WASHERFIG. 44 AUDIO (GA)FIG. 45 AUDIO (GL)FIG. 46 AUDIO (GX,GS)

FIG. 37B WIRING HARNESS (TYPE 2:(GA,GL,GX))

FIG. 37B WIRING HARNESS (TYPE 2:(GA,GL,GX))
No No. Part Description Qty Price Per Pcs Remarks
1-2 36601-67LB0-000 HARNESS ASSY, MAIN 1 Rp1.634.000 (GL,GX):5MT
1-1 36601-67LA0-000 HARNESS ASSY, MAIN 1 Rp1.612.000 GA
1-3 36601-67LC0-000 HARNESS ASSY, MAIN 1 Rp1.713.500 (GL,GX):5AGS
2-1 09481-10504-000 •FUSE (10A) 1 Rp12.500 5MT
2-2 09481-10504-000 •FUSE (10A) 3 Rp12.500 5AGS
3 09481-15504-000 •FUSE (15A) 5 Rp13.000
4 09481-30504-000 •FUSE (30A) 3 Rp15.000
5-1 09481-40403-000 •FUSE (40A) 1 Rp51.500 (GL,GX):5MT
5-2 09481-40403-000 •FUSE (40A) 2 Rp51.500 (GL,GX):5AGS
6 36717-67L30-000 COVER, RELAY BOX 1 Rp81.500
7 36712-67L10-000 BRACKET, RELAY BOX 1 Rp17.000
8 09115-06005-000 BOLT (6X16) 2 Rp14.000
9 09159-06076-000 NUT 3 Rp19.500
10-3 36602-67L70-000 HARNESS ASSY, INSTRUMENT PANEL 1 Rp852.500 GL:5AGS
10-4 36602-67L50-000 HARNESS ASSY, INSTRUMENT PANEL 1 Rp860.500 GX
10-2 36602-67L40-000 HARNESS ASSY, INSTRUMENT PANEL 1 Rp794.000 GL:5MT
10-1 36602-67L30-000 HARNESS ASSY, INSTRUMENT PANEL 1 Rp650.000 GA
11 09115-06005-000 BOLT (6X16) 2 Rp14.000
12 01550-0612B-000 SCREW 1 Rp16.500
13-1 36603-67L30-000 HARNESS ASSY, FLOOR 1 Rp1.261.000 GA
13-2 36603-67L40-000 HARNESS ASSY, FLOOR 1 Rp1.595.500 (GL,GX):5MT
13-3 36603-67LA0-000 HARNESS ASSY, FLOOR 1 Rp1.713.500 (GL,GX):5AGS
14 09481-10504-000 •FUSE (10A) 11 Rp12.500
15 09481-15504-000 •FUSE (15A) 4 Rp13.000
16 09481-20504-000 •FUSE (20A) 2 Rp14.500
17 09481-30504-000 •FUSE (30A) 1 Rp15.000
18 09481-30403-000 •FUSE (30A) 1 Rp41.000
19 36930M82000-000
SUB: 36930M82010-000		 COVER, FUEL HARNESS 1 Rp6.500
20 36930M82000-000
SUB: 36930M82010-000		 COVER, FLOOR HARNESS 2 Rp6.500
21 09115-06005-000 BOLT (6X16) 2 Rp14.000
22 08316-1008A-000
SUB: 08316B1008AN000		 NUT 2 Rp3.500
23-1 36605-67L00-000 HARNESS ASSY, ENGINE 1 Rp2.390.000 5MT
23-2 36605-67LA0-000 HARNESS ASSY, ENGINE 1 Rp2.113.000 5AGS
24 36694-68K10-000
SUB: 36694B68K00N000		 •COVER, BATTERY TERMINAL 1 Rp98.000
25 36739-62J00-000 •FUSE, BATTERY 1 Rp298.500
26 DISCONTINUE
SUB: 01550B0612AN000		 BOLT 1 -
27-1 36680-67LA0-000 HARNESS ASSY, BACK DOOR 1 Rp86.500 GA,GL
27-2 36680-67LB0-000 HARNESS ASSY, BACK DOOR 1 Rp118.000 GX
28 36994M68K00-000 CAP, FR DOOR HOLE B 2 Rp10.500 GA (BODY SIDE)
29 36994M68K20-000 CAP, FR DOOR HOLE D 2 Rp12.500 GA (DOOR SIDE)
30 36756-67L90-000 WIRE, DRIVER DOOR 1 Rp196.500 GL,GX
31 36757-67L90-000 WIRE, PASSENGER DOOR 1 Rp160.000 GL,GX
32 36994-82M00-000 CAP, DOOR HOLE B 2 Rp29.000 GA (BODY SIDE)
33 36994-82M10-000 CAP, DOOR HOLE D 2 Rp29.000 GA (DOOR SIDE)
34-1 36751-67LJ0-000 WIRE, REAR DOOR RH 1 Rp72.000 GL
34-2 36751-67LK0-000 WIRE, REAR DOOR RH 1 Rp82.500 GX
35-1 36751-67LJ0-000 WIRE, REAR DOOR LH 1 Rp72.000 GL
35-2 36751-67LL0-000 WIRE, REAR DOOR LH 1 Rp73.500 GX
36 77191-79F00-000
SUB: 77191B79F00N000		 FILM, BACK DOOR SIDE CUSHION 2 Rp7.500 GA
37 38860-77M00-000
SUB: 38860B77M00N000		 RELAY ASSY, STARTER 1 Rp45.000
38 38860-77M00-000
SUB: 38860B77M00N000		 RELAY ASSY, RADIATOR 1 Rp45.000
39 38860-77M00-000
SUB: 38860B77M00N000		 RELAY ASSY, HETER 1 Rp45.000
40 38860-77M00-000
SUB: 38860B77M00N000		 RELAY ASSY, HORN 1 Rp45.000
41 38860-77M00-000
SUB: 38860B77M00N000		 RELAY ASSY, FUEL INJECTION 1 Rp45.000
42 38860-77M00-000
SUB: 38860B77M00N000		 RELAY ASSY, FUEL PUMP 1 Rp45.000
43 38860-77M00-000
SUB: 38860B77M00N000		 RELAY ASSY, BACK UP LAMP 1 Rp45.000 5AGS
44 38860-76F01-000
SUB: 38860B76F01N000		 RELAY ASSY, A/C 1 Rp47.000
