KARIMUN WAGON R TIPE 1 & 2

Preview Engine Transmission Electrical Suspension Body
< KEMBALI KE THUMBNAIL FIG. 28 ENGINE ELECTRICAL (TYPE 1)FIG. 28A ENGINE ELECTRICAL (TYPE 2)FIG. 29 STARTING MOTORFIG. 30 GENERATOR (TYPE 1)FIG. 30A GENERATOR (TYPE 2)FIG. 31 BATTERY (5MT)FIG. 31A BATTERY (5AGS)FIG. 32 SPEEDOMETER (GA)FIG. 34 HEADLAMP (GA,GL,GX)FIG. 34A HEADLAMP (GS)FIG. 35 REAR LAMPFIG. 36 ROOM LAMPFIG. 37 WIRING HARNESS (TYPE 1:(GA,GL,GX))FIG. 37A WIRING HARNESS (TYPE 1:(GS))FIG. 37B WIRING HARNESS (TYPE 2:(GA,GL,GX))FIG. 37C WIRING HARNESS (TYPE 2:(GS))FIG. 38 ENGINE HARNESS BRACKET (5MT)FIG. 38A ENGINE HARNESS BRACKET (5AGS)FIG. 39 ELECTRICAL CONTROL (TYPE 1)FIG. 39A ELECTRICAL CONTROL (TYPE 2)FIG. 40 LOCK SET (GA,GL)FIG. 41 LOCK SET (GX,GS)FIG. 42 FRONT WINDOW WIPERFIG. 43 WINDOW WASHERFIG. 44 AUDIO (GA)FIG. 45 AUDIO (GL)FIG. 46 AUDIO (GX,GS)

FIG. 35 REAR LAMP

FIG. 35 REAR LAMP
No No. Part Description Qty Price Per Pcs Remarks
1 35650-67L11-000 LAMP UNIT, RR COMBINATION RH 1 Rp533.000
2 35658-67L10-000
SUB: 35658B67L10N000		 SOCKET & CORD ASSY 1 Rp106.500
3 09471-12045-000
SUB: 09471B12045N000		 BULB (12V,21W) 1 Rp13.500
4 09471-12046-000
SUB: 09471B12046N000		 BULB (12V,21/5W) 1 Rp21.500
5 09471-12146-000
SUB: 09471B12146N000		 BULB (12V,16W) 1 Rp39.500
6 35670-67L11-000 LAMP UNIT, RR COMBINATION RH 1 Rp533.000
7 35658-67L10-000
SUB: 35658B67L10N000		 SOCKET & CORD ASSY 1 Rp106.500
8 09471-12045-000
SUB: 09471B12045N000		 BULB (12V,21W) 1 Rp13.500
9 09471-12046-000
SUB: 09471B12046N000		 BULB (12V,21/5W) 1 Rp21.500
10 09471-12146-000
SUB: 09471B12146N000		 BULB (12V,16W) 1 Rp39.500
11 35153-63G00-000
SUB: 35153B67L20N000		 GROMMET, REAR LAMP UPPER 2 Rp30.000
12 35153-67L10-000
SUB: 35153B67L10N000		 GROMMET, REAR LAMP LOWER 2 Rp7.000
13 02162-0616A-000 SCREW 4 Rp3.000
14 35910M67L03-000
SUB: 35910M67L01-000		 LAMP ASSY, LICENSE 1 Rp56.500 RH
15 09471-12216-000
SUB: 09471B12216N000		 •BULB (12V,5W) 1 Rp15.000
16 35910M83K03-000
SUB: 35910M83K01-000		 LAMP ASSY, LICENSE 1 Rp49.000 LH
17 09471-12216-000
SUB: 09471B12216N000		 •BULB (12V,5W) 1 Rp15.000

*Harga dapat berubah sewaktu-waktu tanpa pemberitahuan terlebih dahulu.
