  3. KARIMUN WAGON R TIPE 1 & 2
  4. Electrical
  5. FIG. 37 WIRING HARNESS (TYPE 1:(GA,GL,GX))

KARIMUN WAGON R TIPE 1 & 2

Preview Engine Transmission Electrical Suspension Body
< KEMBALI KE THUMBNAIL FIG. 28 ENGINE ELECTRICAL (TYPE 1)FIG. 28A ENGINE ELECTRICAL (TYPE 2)FIG. 29 STARTING MOTORFIG. 30 GENERATOR (TYPE 1)FIG. 30A GENERATOR (TYPE 2)FIG. 31 BATTERY (5MT)FIG. 31A BATTERY (5AGS)FIG. 32 SPEEDOMETER (GA)FIG. 34 HEADLAMP (GA,GL,GX)FIG. 34A HEADLAMP (GS)FIG. 35 REAR LAMPFIG. 36 ROOM LAMPFIG. 37 WIRING HARNESS (TYPE 1:(GA,GL,GX))FIG. 37A WIRING HARNESS (TYPE 1:(GS))FIG. 37B WIRING HARNESS (TYPE 2:(GA,GL,GX))FIG. 37C WIRING HARNESS (TYPE 2:(GS))FIG. 38 ENGINE HARNESS BRACKET (5MT)FIG. 38A ENGINE HARNESS BRACKET (5AGS)FIG. 39 ELECTRICAL CONTROL (TYPE 1)FIG. 39A ELECTRICAL CONTROL (TYPE 2)FIG. 40 LOCK SET (GA,GL)FIG. 41 LOCK SET (GX,GS)FIG. 42 FRONT WINDOW WIPERFIG. 43 WINDOW WASHERFIG. 44 AUDIO (GA)FIG. 45 AUDIO (GL)FIG. 46 AUDIO (GX,GS)

FIG. 37 WIRING HARNESS (TYPE 1:(GA,GL,GX))

FIG. 37 WIRING HARNESS (TYPE 1:(GA,GL,GX))
No No. Part Description Qty Price Per Pcs Remarks
1-2 36601-67L10-000
SUB: 36601B67L10N000		 HARNESS ASSY, MAIN 1 Rp1.331.000 GL,GX
1-1 36601-67L00-000
SUB: 36601B67L00N000		 HARNESS ASSY, MAIN 1 Rp1.339.500 GA
2 09481-10504-000 •FUSE (10A) 1 Rp12.500
3 09481-15504-000 •FUSE (15A) 3 Rp13.000
4 09481-30504-000 •FUSE (30A) 3 Rp15.000
5 09481-40403-000 •FUSE (40A) 1 Rp51.500
6 36717-67L10-000
SUB: 36717B67L10N000		 COVER, RELAY BOX 1 Rp80.500
7 36712-67LA0-000
SUB: 36712B67LA0N000		 BRACKET, RELAY BOX 1 Rp17.000
8 09115-06005-000 BOLT (6X16) 2 Rp14.000
9 09159-06076-000 NUT 3 Rp19.500
10-1 36602-67L00-000
SUB: 36602B67L00N000		 HARNESS ASSY, INSTRUMENT PANEL 1 Rp704.500 GA
10-2 36602-67L10-000
SUB: 36602B67L10N000		 HARNESS ASSY, INSTRUMENT PANEL 1 Rp889.000 GL
10-3 36602-67L20-000
SUB: 36602B67L20N000		 HARNESS ASSY, INSTRUMENT PANEL 1 Rp926.000 GX
11 09115-06005-000 BOLT (6X16) 2 Rp14.000
12 01550-0612B-000 SCREW 1 Rp16.500
13-1 36603-67L00-000
SUB: 36603B67L00N000		 HARNESS ASSY, FLOOR 1 Rp1.447.000 GA
13-2 36603-67L10-000
SUB: 36603B67L10N000		 HARNESS ASSY, FLOOR 1 Rp1.673.500 GL,GX
14 09481-10504-000 •FUSE (10A) 11 Rp12.500
15 09481-15504-000 •FUSE (15A) 4 Rp13.000
16 09481-20504-000 •FUSE (20A) 2 Rp14.500
17 09481-30504-000 •FUSE (30A) 1 Rp15.000
18 09481-30403-000 •FUSE (30A) 1 Rp41.000
19 36930M82000-000
SUB: 36930M82010-000		 COVER, FUEL HARNESS 1 Rp6.500
20 36930M82000-000
SUB: 36930M82010-000		 COVER, FLOOR HARNESS 2 Rp6.500
21 09115-06005-000 BOLT (6X16) 3 Rp14.000
22 08316-1008A-000
SUB: 08316B1008AN000		 NUT 2 Rp3.500
23 36650-67L50-000
SUB: 36650B67L50N000		 HARNESS ASSY, ENGINE 1 Rp1.516.000
24 36694-68K10-000
SUB: 36694B68K00N000		 •COVER, BATTERY TERMINAL 1 Rp98.000
25 36739-62J00-000 •FUSE, BATTERY 1 Rp298.500
26 01550-0616A-000
SUB: 01550B0616AN000		 BOLT 1 Rp3.500
27-1 36680-67L60-000
SUB: 36680B67L60N000		 HARNESS ASSY, BACK DOOR 1 Rp94.000 GA,GL
27-2 36680-67LB0-000
SUB: 36680B67L80N000		 HARNESS ASSY, BACK DOOR 1 Rp118.000 GX
28 36995-67L20-000
SUB: 36995B67L20N000		 GROMMET, FR DOOR 2 Rp26.500 GA
29 36756-67L70-000
SUB: 36756B67L70N000		 WIRE, DRIVER DOOR 1 Rp196.000 GL,GX
30 36757-67L70-000
SUB: 36757B67L70N000		 WIRE, PASSENGER DOOR 1 Rp159.500 GL,GX
31 36995-67L30-000
SUB: 36995B67L30N000		 GROMMET, REAR DOOR HARN 2 Rp44.500 GA
32-1 36751-67L70-000
SUB: 36751B67L70N000		 WIRE, REAR DOOR RH 1 Rp72.000 GL
32-2 36751-67LK0-000
SUB: 36751B67L80N000		 WIRE, REAR DOOR RH 1 Rp82.500 GX
33-1 36751-67L70-000
SUB: 36751B67L70N000		 WIRE, REAR DOOR LH 1 Rp72.000 GL
33-2 36751-67LH0-000
SUB: 36751B67LH0N000		 WIRE, REAR DOOR LH 1 Rp75.500 GX
34 77191-79F00-000
SUB: 77191B79F00N000		 FILM, BACK DOOR SIDE CUSHION 2 Rp7.500 GA
35 38860-77M00-000
SUB: 38860B77M00N000		 RELAY ASSY, STARTER 1 Rp45.000
36 38860-77M00-000
SUB: 38860B77M00N000		 RELAY ASSY, RADIATOR 1 Rp45.000
37 38860-77M00-000
SUB: 38860B77M00N000		 RELAY ASSY, HETER 1 Rp45.000
38 38860-77M00-000
SUB: 38860B77M00N000		 RELAY ASSY, HORN 1 Rp45.000
39 38860-77M00-000
SUB: 38860B77M00N000		 RELAY ASSY, FUEL INJECTION 1 Rp45.000
40 38860-77M00-000
SUB: 38860B77M00N000		 RELAY ASSY, FUEL PUMP 1 Rp45.000
41 38860-76F01-000
SUB: 38860B76F01N000		 RELAY ASSY, A/C 1 Rp47.000

*Harga dapat berubah sewaktu-waktu tanpa pemberitahuan terlebih dahulu.
