  3. KARIMUN WAGON R TIPE 1 & 2
  4. Electrical
  5. FIG. 37C WIRING HARNESS (TYPE 2:(GS))

KARIMUN WAGON R TIPE 1 & 2

Preview Engine Transmission Electrical Suspension Body
< KEMBALI KE THUMBNAIL FIG. 28 ENGINE ELECTRICAL (TYPE 1)FIG. 28A ENGINE ELECTRICAL (TYPE 2)FIG. 29 STARTING MOTORFIG. 30 GENERATOR (TYPE 1)FIG. 30A GENERATOR (TYPE 2)FIG. 31 BATTERY (5MT)FIG. 31A BATTERY (5AGS)FIG. 32 SPEEDOMETER (GA)FIG. 34 HEADLAMP (GA,GL,GX)FIG. 34A HEADLAMP (GS)FIG. 35 REAR LAMPFIG. 36 ROOM LAMPFIG. 37 WIRING HARNESS (TYPE 1:(GA,GL,GX))FIG. 37A WIRING HARNESS (TYPE 1:(GS))FIG. 37B WIRING HARNESS (TYPE 2:(GA,GL,GX))FIG. 37C WIRING HARNESS (TYPE 2:(GS))FIG. 38 ENGINE HARNESS BRACKET (5MT)FIG. 38A ENGINE HARNESS BRACKET (5AGS)FIG. 39 ELECTRICAL CONTROL (TYPE 1)FIG. 39A ELECTRICAL CONTROL (TYPE 2)FIG. 40 LOCK SET (GA,GL)FIG. 41 LOCK SET (GX,GS)FIG. 42 FRONT WINDOW WIPERFIG. 43 WINDOW WASHERFIG. 44 AUDIO (GA)FIG. 45 AUDIO (GL)FIG. 46 AUDIO (GX,GS)

FIG. 37C WIRING HARNESS (TYPE 2:(GS))

FIG. 37C WIRING HARNESS (TYPE 2:(GS))
No No. Part Description Qty Price Per Pcs Remarks
1-2 36601-67LG0-000
SUB: 36601-67LE0-000		 HARNESS ASSY, MAIN 1 Rp1.832.500 5AGS
1-1 36601-67LF0-000
SUB: 36601-67LD0-000		 HARNESS ASSY, MAIN 1 Rp1.677.000 5MT
2-2 09481-10504-000 •FUSE (10A) 3 Rp12.500 5AGS
2-1 09481-10504-000 •FUSE (10A) 1 Rp12.500 5MT
3 09481-15504-000 •FUSE (15A) 5 Rp13.000
4 09481-30504-000 •FUSE (30A) 3 Rp15.000
5-1 09481-40403-000 •FUSE (40A) 1 Rp51.500 5MT
5-2 09481-40403-000 •FUSE (40A) 2 Rp51.500 5AGS
6 36717-67L30-000 COVER, RELAY BOX 1 Rp81.500
7 36712-67L10-000 BRACKET, RELAY BOX 1 Rp17.000
8 09115-06005-000 BOLT (6X16) 2 Rp14.000
9 09159-06076-000 NUT 3 Rp19.500
10 36602-67L50-000 HARNESS ASSY, INSTRUMENT PANEL 1 Rp860.500
11 09115-06005-000 BOLT (6X16) 2 Rp14.000
12 02162-0612A-000 SCREW 1 Rp11.000
13-1 36603-67L40-000 HARNESS ASSY, FLOOR 1 Rp1.595.500 5MT
13-2 36603-67LA0-000 HARNESS ASSY, FLOOR 1 Rp1.713.500 5AGS
14 09481-10504-000 •FUSE (10A) 11 Rp12.500
15 09481-15504-000 •FUSE (15A) 4 Rp13.000
16 09481-20504-000 •FUSE (20A) 2 Rp14.500
17 09481-30504-000 •FUSE (30A) 1 Rp15.000
18 09481-30403-000 •FUSE (30A) 1 Rp41.000
19 36930M82000-000
SUB: 36930M82010-000		 COVER, FUEL HARNESS 1 Rp6.500
20 36930M82000-000
SUB: 36930M82010-000		 COVER, FLOOR HARNESS 2 Rp6.500
21 09115-06005-000 BOLT (6X16) 2 Rp14.000
22 08316-1008A-000
SUB: 08316B1008AN000		 NUT 2 Rp3.500
23-1 36605-67L00-000 HARNESS ASSY, ENGINE 1 Rp2.390.000 5MT
23-2 36605-67LA0-000 HARNESS ASSY, ENGINE 1 Rp2.113.000 5AGS
24 36694-68K10-000
SUB: 36694B68K00N000		 •COVER, BATTERY TERMINAL 1 Rp98.000
25 36739-62J00-000 •FUSE, BATTERY 1 Rp298.500
26 DISCONTINUE
SUB: 01550B0612AN000		 BOLT 1 -
27 36680-67LB0-000 HARNESS ASSY, BACK DOOR 1 Rp118.000
28 36756-67L90-000 WIRE, DRIVER DOOR 1 Rp196.500
29 36757-67L90-000 WIRE, PASSENGER DOOR 1 Rp160.000
30 36751-67LK0-000 WIRE, REAR DOOR RH 1 Rp82.500
31 36751-67LL0-000 WIRE, REAR DOOR LH 1 Rp73.500
32 38860-77M00-000
SUB: 38860B77M00N000		 RELAY ASSY, STARTER 1 Rp45.000
33 38860-77M00-000
SUB: 38860B77M00N000		 RELAY ASSY, RADIATOR 1 Rp45.000
34 38860-77M00-000
SUB: 38860B77M00N000		 RELAY ASSY, HEADLAMP LOW RH 1 Rp45.000
35 38860-77M00-000
SUB: 38860B77M00N000		 RELAY ASSY, HEADLAMP LOW LH 1 Rp45.000
36 38860-77M00-000
SUB: 38860B77M00N000		 RELAY ASSY, HETER 1 Rp45.000
37 38860-77M00-000
SUB: 38860B77M00N000		 RELAY ASSY, HORN 1 Rp45.000
38 38860-77M00-000
SUB: 38860B77M00N000		 RELAY ASSY, MAIN 1 Rp45.000
39 38860-77M00-000
SUB: 38860B77M00N000		 RELAY ASSY, FUEL 1 Rp45.000
40 38860-76F01-000
SUB: 38860B76F01N000		 RELAY ASSY, A/C 1 Rp47.000
41 38860-76F01-000
SUB: 38860B76F01N000		 RELAY ASSY, BACK UP LAMP 1 Rp47.000 5AGS

*Harga dapat berubah sewaktu-waktu tanpa pemberitahuan terlebih dahulu.
