KARIMUN WAGON R TIPE 1 & 2

Preview Engine Transmission Electrical Suspension Body
< KEMBALI KE THUMBNAIL FIG. 28 ENGINE ELECTRICAL (TYPE 1)FIG. 28A ENGINE ELECTRICAL (TYPE 2)FIG. 29 STARTING MOTORFIG. 30 GENERATOR (TYPE 1)FIG. 30A GENERATOR (TYPE 2)FIG. 31 BATTERY (5MT)FIG. 31A BATTERY (5AGS)FIG. 32 SPEEDOMETER (GA)FIG. 34 HEADLAMP (GA,GL,GX)FIG. 34A HEADLAMP (GS)FIG. 35 REAR LAMPFIG. 36 ROOM LAMPFIG. 37 WIRING HARNESS (TYPE 1:(GA,GL,GX))FIG. 37A WIRING HARNESS (TYPE 1:(GS))FIG. 37B WIRING HARNESS (TYPE 2:(GA,GL,GX))FIG. 37C WIRING HARNESS (TYPE 2:(GS))FIG. 38 ENGINE HARNESS BRACKET (5MT)FIG. 38A ENGINE HARNESS BRACKET (5AGS)FIG. 39 ELECTRICAL CONTROL (TYPE 1)FIG. 39A ELECTRICAL CONTROL (TYPE 2)FIG. 40 LOCK SET (GA,GL)FIG. 41 LOCK SET (GX,GS)FIG. 42 FRONT WINDOW WIPERFIG. 43 WINDOW WASHERFIG. 44 AUDIO (GA)FIG. 45 AUDIO (GL)FIG. 46 AUDIO (GX,GS)

FIG. 34A HEADLAMP (GS)

FIG. 34A HEADLAMP (GS)
No No. Part Description Qty Price Per Pcs Remarks
1 35121M67LA3-000
SUB: 35121M67LA0-000		 UNIT, HEADLAMP RH 1 Rp2.234.500
2 35125M67LA0-000 COVER, SOCKET 2 Rp22.500
3 35618M67LA0-000 SOCKET, TURN SIGNAL 1 Rp45.000
4 09471-12188-000 BULB (12V55W/H7/PX26D/PHILIPS) 2 Rp209.000
5 09471-12216-000
SUB: 09471B12216N000		 BULB (12V,5W) 1 Rp15.000
6 09471-12245-000
SUB: 09471B12245N000		 BULB (12V21W,PY21W) (AMBER) 1 Rp30.500
7 35321M67LA3-000
SUB: 35321M67LA0-000		 UNIT, HEADLAMP LH 1 Rp2.234.500
8 35125M67LA0-000 COVER, SOCKET 2 Rp22.500
9 35618M67LA0-000 SOCKET, TURN SIGNAL 1 Rp45.000
10 09471-12188-000 BULB (12V55W/H7/PX26D/PHILIPS) 2 Rp209.000
11 09471-12216-000
SUB: 09471B12216N000		 BULB (12V,5W) 1 Rp15.000
12 09471-12245-000
SUB: 09471B12245N000		 BULB (12V21W,PY21W) (AMBER) 1 Rp30.500
13 09122-76006-000 SCREW (6X16) 8 Rp13.000
14 09409-08327-000 CLIP 2 Rp15.000
15 35175-67LA0-000
SUB: 35175B67LA0N000		 CONNECTOR, HEADLAMP LEVELING 2 Rp32.500
16 36410-61J01-000
SUB: 36410B61J00N000		 LAMP ASSY, SIDE TURN SIGNAL 2 Rp56.000
17 990H0-990AL-044 FOG LAMP SET 1 Rp1.194.500 NOT ILLUSTRATED

*Harga dapat berubah sewaktu-waktu tanpa pemberitahuan terlebih dahulu.
