Preview Engine Transmission Electrical Suspension Body

No	No. Part	Description	Qty	Price Per Pcs
1	38101-77501-000 SUB: 38101-77500-000	MOTOR ASSY, WIPER	1	Rp4.676.500
2	02162-0610A-000	BOLT	4	Rp5.000
3	38102-77500-000	LINK ASSY, WIPER	1	Rp1.076.500
4	38271-74300-000	WASHER	2	Rp74.000
5	09159-1800-000	NUT	2	-
6	38274-74300-000	CAP	2	Rp22.000
7	38310-77500-000 SUB: 38310-77500L000	ARM ASSY, WIPER RH	1	Rp139.500
8	38310-77510-000 SUB: 38310-77510L000	ARM ASSY, WIPER LH	1	Rp137.500
9	38315-78400-000 SUB: 38315-78400L000	.COVER, ARM HEAD	2	Rp9.500
10	38340-50F00-000	BLADE ASSY, WIPER RH	1	Rp432.500
11	38346-56B00-000	.BLADE, RH	1	Rp111.000
12	38340-77510-000	BLADE ASSY, WIPER LH	1	Rp281.000
13	38346-60C10-000	.BLADE, LH	1	Rp88.000
14	08316-1008A-000 SUB: 08316B1008AN000	NUT	2	Rp3.500
15	38480-77500-000	NOZZLE ASSY, WASHER	1	Rp277.000
16	38491-61A00-000	.HOSE, WASHER (L:1000!100)	1	Rp47.500
17	38833M79500-000 SUB: 38496-61A00-000	.VALVE	1	Rp8.000
18	38450-77500-000	TANK, WASHER	1	-
19	38453M75000-000	.GROMMET	1	Rp4.500
20	38410-66113-000	PUMP ASSY, WASHER	1	Rp865.000
21	38491-61A00-000	HOSE, WASHER (L:340)	1	Rp47.500
22	38496-56B00-000	CONNECTOR, HOSE	1	Rp33.500
