FIG.33 HEADLAMP AND ROOM LAMP

FIG.33 HEADLAMP AND ROOM LAMP
No No. Part Description Qty Price Per Pcs Remarks
1 35121-77502-27N LAMP UNIT, RH (SILVER) 1 Rp2.604.500
2 35321-77502-27N LAMP UNIT, LH (SILVER) 1 Rp2.604.500
3 09471-12060-000 BULB (12V,65/60W) 2 Rp882.000
4 35125-70G10-000 COVER, SOCKET 2 Rp91.000
5 09471-12152-000
SUB: 09471-12152L000		 BULB (12V,27/8W) 2 Rp72.000
6 35170-77500-000 SOCKET 2 Rp156.000
7 09132-05029-000 SCREW 2 Rp20.500
8 01550-0612B-000 BOLT 4 Rp16.500
9 35659-70B00-000 GROMMET 2 Rp41.000
10 36210-85060-4GF LAMP ASSY, ROOM (BEIGE) 1 Rp1.947.000
11 36212-78001-000 .LENS, ROOM LAMP 1 Rp55.000
12 09471-12073-000 .BULB (12V,5W) 1 Rp26.500
13 03241-0512A-000
SUB: 03241B0512AN000		 SCREW 2 Rp3.500

*Harga dapat berubah sewaktu-waktu tanpa pemberitahuan terlebih dahulu.
