FUTURA SL415

Preview Engine Transmission Electrical Suspension Body
< KEMBALI KE THUMBNAIL FIG.28 ELECTRICAL CONTROLFIG.29 STARTING MOTORFIG.30 GENERATORFIG.31 BATTERYFIG.32 SPEEDOMETERFIG.33 HEADLAMP AND ROOM LAMPFIG.34 REAR LAMPFIG.35 WIRING HARNESSFIG.36 SWITCHFIG.37 WINDSHIELD WIPER AND WASHER

FIG.36 SWITCH

FIG.36 SWITCH
No No. Part Description Qty Price Per Pcs Remarks
1 37400-77510-000
SUB: 37400B77510N000		 SWITCH ASSY, COMBINATION 1 Rp644.000
2 03211-0516A-000 SCREW 4 Rp13.000
3 37740-66010-000 SWITCH ASSY, STOP LAMP 1 Rp137.500
4 09140-10043-000 NUT 1 Rp14.500
5 37940-50A00-000 SWITCH ASSY, PARKING BRAKE 1 Rp95.500
6 DISCONTINUE
SUB: 09308-03005-000		 GROMMET 1 -
7 38610M76G40-000
SUB: 38610M76G00-000		 RELAY ASSY, TURN SIGNAL 1 Rp144.000
8 77400-79891-000 LOCK SET 1 Rp1.326.500 W/PICK UP
9 37100-79800-0CB LOCK SET 1 Rp3.294.000 W/MINI BUS
10 37011-79002-000
SUB: 37011B79002N000		 .SWITCH ASSY, IGNITION 1 Rp268.500
11 DISCONTINUE
SUB: 77400-70812-000		 .CYLINDER, FRONT DOOR LOCK RH 1 -
12 DISCONTINUE
SUB: 77400-70832-000		 .CYLINDER, FRONT DOOR LOCK LH 1 -
13 DISCONTINUE
SUB: 77400-70832-000		 .CYLINDER, REAR DOOR LOCK 1 - W/MINI BUS
14 DISCONTINUE
SUB: 82500-85811-0CB		 .CYLINDER, BACK DOOR LOCK 1 - W/MINI BUS
15 DISCONTINUE
SUB: 37145-73302-000		 KEY, BLANK 1 - OPT
16 DISCONTINUE
SUB: 09404-08206-000		 CLAMP 1 -

*Harga dapat berubah sewaktu-waktu tanpa pemberitahuan terlebih dahulu.
