FIG.34 REAR LAMP

FIG.34 REAR LAMP
No No. Part Description Qty Price Per Pcs Remarks
1 35603-77500-000
SUB: 35603-77500L000		 LAMP ASSY, COMBINATION RH 1 Rp356.500
2 35604-77500-000
SUB: 35604-77500L000		 LAMP ASSY, COMBINATION LH 1 Rp356.500
3 35712-80000-000
SUB: 35712-80000L000		 .LENS, TAIL/STOP 2 Rp20.000
4 03212-0525B-000
SUB: 03212-05253-000		 .SCREW 8 Rp108.500
5 35662-80000-000
SUB: 35662-80000L000		 .LENS, TURN SIGNAL 2 Rp17.500
6 36252-80000-000
SUB: 36252-80000L000		 .LENS, BACK UP RH 1 Rp16.000
7 36272-80000-000
SUB: 36272-80000L000		 .LENS, BACK UP LH 1 Rp18.500
8 09471-12045-000
SUB: 09471B12045N000		 .BULB (12V,21W) 4 Rp13.500
9 09471-12083-000 .BULB (12V,21/5W) 2 Rp62.000
10 03141-0516B-000
SUB: 03141M0512A-000		 SCREW, EARTH 2 Rp3.500
11 35910-77500-000 LAMP ASSY, LICENSE 1 Rp291.000
12 09471-12081-000
SUB: 09471B12081N000		 .BULB (12V,5W) 1 Rp11.000
13 03112-0416A-000
SUB: 03112B0416AN000		 .SCREW 2 Rp23.500
14 03141-0516B-000
SUB: 03141M0512A-000		 SCREW 1 Rp3.500

*Harga dapat berubah sewaktu-waktu tanpa pemberitahuan terlebih dahulu.
