FUTURA SL415

Preview Engine Transmission Electrical Suspension Body
< KEMBALI KE THUMBNAIL FIG.28 ELECTRICAL CONTROLFIG.29 STARTING MOTORFIG.30 GENERATORFIG.31 BATTERYFIG.32 SPEEDOMETERFIG.33 HEADLAMP AND ROOM LAMPFIG.34 REAR LAMPFIG.35 WIRING HARNESSFIG.36 SWITCHFIG.37 WINDSHIELD WIPER AND WASHER

FIG.30 GENERATOR

FIG.30 GENERATOR
No No. Part Description Qty Price Per Pcs Remarks
1 31400-77512-000
SUB: 31400B77510N000		 GENERATOR ASSY 1 Rp2.847.000
2 31171-60A21-000 .PULLEY 1 Rp789.500
3 31410-77510-000
SUB: 31410B77510N000		 .STATOR ASSY 1 Rp926.500
4 DISCONTINUE
SUB: 31514-61J00-000		 .TERMINAL SET 1 -
5 31582-50F40-000
SUB: 31582-50F21-000		 .BEARING 1 Rp407.500
6 31585-83E00-000 .RETAINER, BEARING 1 Rp73.000
7 31586-86520-000 .SCREW SET 1 Rp67.500
8 DISCONTINUE
SUB: 31616-83E00-000		 .BUSH 1 -
9 DISCONTINUE
SUB: 31621-66D00-000		 .RECTIFIER ASSY 1 -
10 31651-86520-000 .SCREW SET 1 Rp78.000
11 DISCONTINUE
SUB: 31710B77510N000		 .ROTOR ASSY 1 -
12 DISCONTINUE
SUB: 31612-60A10-000		 ..BEARING, REAR 1 -
13 31775-50F20-000 .NUT 1 Rp74.500
14 32500-77510-000
SUB: 32500B77510N000		 .REGULATOR ASSY 1 Rp1.147.500
15 31631-60F30-000 ..BRUSH SET 2 Rp121.000

*Harga dapat berubah sewaktu-waktu tanpa pemberitahuan terlebih dahulu.
