FIG.35 WIRING HARNESS

No	No. Part	Description	Qty	Price Per Pcs
1	36610-77520-000 SUB: 36610-77520L000	HARNESS ASSY, WIRING NO.1	1	Rp1.339.500
2	36717-775A0-000 SUB: 36717B775A0N000	.COVER, FUSE BOX	1	Rp691.500
3	09481-10501-000 SUB: 09481M10501-000	.FUSE, 10A	4	Rp12.000
4	09481-15501-000 SUB: 09481M15501-000	.FUSE, 15A	9	Rp12.000
5	09481-30401-000	.FUSE, 30A	1	Rp42.000
6	38860-76F01-000 SUB: 38860B76F01N000	.RELAY ASSY, STARTING MOTOR	1	Rp47.000
7	36614-77500-000	BRACKET, FUSE BOX	1	-
8	09115-06005-000	BOLT, HARNESS GROUND	1	Rp14.000
9	09407-17402-000 SUB: 09407-14408-000	CLAMP, HARNESS NO.1	4	Rp39.000
10	33941-77500-000	BRACKET, CONNECTOR	1	-
11	01550-0612B-000	BOLT	1	Rp16.500
12	36650-77542-000 SUB: 36650B77540N000	HARNESS ASSY, WIRING NO.5	1	Rp2.357.000
13	36651-77500-000	BRACKET, HARNESS	1	-
14	36651-77520-000	BRACKET, HARNESS	1	-
15	09115-06005-000	BOLT, HARNESS GROUND	1	Rp14.000
16	09407-05403-000	CLAMP, FUEL GAUGE HARNESS	6	Rp13.000
17	09407-17402-000 SUB: 09407-14408-000	CLAMP, HARNESS NO.5	9	Rp39.000
18	01550-0612B-000	BOLT, HARNESS BRACKET	2	Rp16.500
19	36651-51G00-000 SUB: 36651B51G00N000	BRACKET, HARNESS	1	Rp5.500
20	36651-60G20-000	BRACKET, HARNESS	1	Rp48.000
21	36651-77500-000	BRACKET, HARNESS BACKUP	1	-
22	36651-77510-000	BRACKET, HARNESS	1	-
23	36651-77530-000	BRACKET, HARNESS	1	-
24	36651-77540-000	BRACKET, HARNESS	1	-
25	36655-61J00-000	BRACKET, HARNESS	1	Rp39.500
26	DISCONTINUE SUB: 01550B0612AN000	BOLT, HARNESS GROUND	1	-
27	DISCONTINUE SUB: 01550B0612AN000	BOLT, BRACKET	1	-
28	DISCONTINUE SUB: 36630B77500N000	WIRE, ROOM LAMP	1	-
29	09407-05403-000	CLAMP, ROOM LAMP WIRE	1	Rp13.000
30	DISCONTINUE SUB: 39192-70G00-000	WIRE, TUNER GROUND	1	-
31	09250-02001-000	CAP, RADIO ANTENNA HOLE	2	Rp14.000
32	09250-14003-000	CAP, RADIO ANTENNA	1	Rp18.500
33	38500-77501-000 SUB: 38500-77500L000	HORN ASSY	1	Rp81.000
34	01570-0812A-000	BOLT, HORN	1	Rp18.500
35	02162-0512A-000	SCREW, FUSE BOX	2	Rp11.500
