  5. FIG.33 REAR COMBINATION LAMP

AXELO

Preview Engine Transmission Electrical Suspension Body
< KEMBALI KE THUMBNAIL FIG.26 STARTING MOTORFIG.27 MAGNETOFIG.28 BATTERYFIG.29 ELECTRICALFIG.30 SPEEDOMETERFIG.31 HEADLAMPFIG.32 FRONT TURN SIGNAL LAMPFIG.33 REAR COMBINATION LAMPFIG.34 WIRING HARNESS

FIG.33 REAR COMBINATION LAMP

FIG.33 REAR COMBINATION LAMP
No No. Part Description Qty Price Per Pcs Remarks
1 35710-10J00-000
SUB: 35710B10J00N000		 LAMP ASSY, REAR COMB 1 Rp181.500
2 35712-10J00-000
SUB: 35712B10J00N000		 ?LENS 1 Rp28.500
3 35713-10J00-000
SUB: 35713B10J00N000		 ?GASKET 1 Rp6.500
4 35713-10J10-000
SUB: 35713B10J10N000		 ?GASKET 1 Rp3.500
5 09471-12114AS01
SUB: 09471B12203N000		 ?BULB (12V10W) 2 Rp14.000
6 09471-12127-000
SUB: 09471B12119N000		 ?BULB (12V18/5W) 1 Rp12.500
7 03211-04206-000
SUB: 03211B04206N000		 ?SCREW 2 Rp3.500
8 35719-10J00-000
SUB: 35719B10J00N000		 ?INNER LENS 1 Rp12.500
9 DISCONTINUE
SUB: 35726B10J00N000		 BRACKET, REAR COMB 1 -
10 35791-10J00-000
SUB: 35791B10J00N000		 SPACER, REAR COMB 2 Rp4.000
11 09160-05045-000
SUB: 09160B05045N000		 WASHER (5.5X18X1) 5 Rp4.500
12 35781-45H00-000
SUB: 35781B45H00N000		 CUSHION, REAR COMB BRACKET 3 Rp3.000
13 09320-09016-000
SUB: 09320-09016L000		 CUSHION 2 Rp4.000
14 01547-0610A-000
SUB: 01547B0612AN000		 BOLT 2 Rp3.000
15 DISCONTINUE
SUB: 02142-0520B-000		 SCREW 2 -
16 03541-0516A-000
SUB: 03541B0516AN000		 SCREW 3 Rp3.500

*Harga dapat berubah sewaktu-waktu tanpa pemberitahuan terlebih dahulu.
