| 1 |
37210-58M00-000 |
SWITCH ASSY, LIGHTING & TURN |
1 |
Rp735.000 |
| |
| 2 |
37285-58M00-000 |
CAP, OPTION SWITCH HOLE |
0 |
Rp56.000 |
| |
| 3 |
37270-58M00-000 |
SWITCH ASSY, FRONT FOG LAMP |
1 |
Rp434.000 |
| |
| 4 |
37310-58M00-000 |
SWITCH ASSY, WIPER & WASHER |
1 |
Rp930.000 |
| |
| 5 |
37480-62J00-000
SUB: 37480B62J00N000 |
CABLE ASSY, CONTACT COIL |
1 |
Rp371.500 |
| |
| 6 |
37430-58M10-5PK |
SWITCH ASSY, HAZARD & SECURITY (BLACK) |
1 |
Rp500.500 |
| |
| 7 |
37740-58M00-000 |
SET, STOP LAMP SWITCH |
1 |
Rp262.000 |
| |
| 8 |
37970-64J00-000 |
SWITCH ASSY, CLUTCHMT |
1 |
Rp507.000 |
MT | |
| 9 |
09140-10043-000 |
NUT MT |
1 |
Rp14.500 |
MT | |
| 10 |
37970-68J00-000 |
SWITCH ASSY, CLUTCH STARTMT |
1 |
Rp512.500 |
MT | |
| 11 |
09140-10043-000 |
NUT MT |
1 |
Rp14.500 |
MT | |
| 12 |
37670M60M10-000
SUB: 37670M60M00-000 |
SWITCH ASSY, DOOR |
4 |
Rp35.000 |
| |
| 13 |
39510-74L00-BKZ |
PANEL UNIT, AUTO A/C(BLACK/CHROME) |
1 |
Rp5.507.500 |
| |
| 14 |
09409-08349-000
SUB: 09409B08342N000 |
•CLIP |
4 |
Rp4.500 |
| |
| 15 |
39530-58M00-000 |
CONTROLLER UNIT, AUTO A/C |
1 |
Rp1.935.500 |
| |
| 16 |
03541-0516A-000
SUB: 03541B0516AN000 |
SCREW |
2 |
Rp3.500 |
| |
| 17 |
37179-58M00-000 |
SWITCH ASSY, BACK DOOR |
1 |
Rp507.000 |
| |
| 18 |
DISCONTINUE
SUB: 09132-04035-000 |
SCREW (4X14) |
2 |
- |
| |
| 19 |
37990-58M03-000
SUB: 37990-58M00-000 |
SWITCH ASSY, POWER WINDOW MAIN |
1 |
Rp1.509.500 |
| |
| 20 |
03541-0410A-000 |
SCREW |
3 |
Rp11.000 |
| |
| 21 |
37995M79M02-000
SUB: 37995-58M00-000 |
SWITCH ASSY, POWER WINDOW SUB |
1 |
Rp109.500 |
| |
| 22 |
03541-0410A-000 |
SCREW |
1 |
Rp11.000 |
| |
| 23 |
37995M79M02-000
SUB: 37995-58M00-000 |
SWITCH ASSY, POWER WINDOW REAR |
2 |
Rp109.500 |
| |
| 24 |
03541-0410A-000 |
SCREW |
2 |
Rp11.000 |
| |
| 25 |
37950-62J31-000
SUB: 37950-62J30-000 |
SWITCH ASSY, MIRROR |
1 |
Rp463.500 |
| |
| 26 |
38500-58M00-000 |
HORN ASSY |
1 |
Rp241.500 |
| |
| 27 |
09115-08001-000 |
BOLT (8X18) |
1 |
Rp21.500 |
| |
| 28 |
36770-58MB2-000
SUB: 36770-58MB0-000 |
CONTROLLER ASSY, BODY ELECTRIC |
1 |
Rp3.757.500 |
| |
| 29 |
08316-1008A-000
SUB: 08316B1008AN000 |
NUT |
2 |
Rp3.500 |
| |
| 30 |
36771-58J00-000 |
LABEL, SECURITY ALARM |
1 |
Rp30.000 |
| |
| 31 |
37171-71L05-000
SUB: 37171-71L03-000 |
CONTROLLER SET, KEYLESS |
1 |
Rp5.736.500 |
| |
| 32 |
37175-57L00-000 |
ANTENNA ASSY, KEYLESS INSIDE |
1 |
Rp524.000 |
| |
| 33 |
37175-57L00-000 |
ANTENNA ASSY, KEYLESS LUGGAGE |
1 |
Rp524.000 |
| |
| 34 |
37175-57L10-000 |
ANTENNA ASSY, KEYLESS BACK |
1 |
Rp524.000 |
| |
| 35 |
37190-71L10-000 |
RECEIVER ASSY, KEYLESS |
1 |
Rp3.469.000 |
| |
| 36 |
38590-82K01-000 |
BUZZER ASSY, KEYLESS |
1 |
Rp448.000 |
| |
| 37 |
08316-1008A-000
SUB: 08316B1008AN000 |
NUT |
2 |
Rp3.500 |
| |
| 38 |
03141-0516B-000
SUB: 03141-0512A-000 |
SCREW |
1 |
Rp3.500 |
| |
| 39 |
95643-58J00-000 |
SENSOR, OUTSIDE AIR TEMP |
1 |
Rp262.000 |
| |
| 40 |
38880-58MA0-000 |
CONTROLLER ASSY, AT |
1 |
Rp11.978.500 |
AT | |
| 41 |
38881-58MA0-000 |
BRACKET, AT CONTAT |
1 |
Rp147.500 |
AT | |
| 42 |
08316-1008A-000
SUB: 08316B1008AN000 |
NUT AT |
1 |
Rp3.500 |
AT | |
| 43 |
02162-0512A-000 |
SCREW AT |
2 |
Rp11.500 |
AT | |
| 44 |
38720-58M05-000
SUB: 38720-58M00-000 |
CONTROLLER ASSY, POWER STEERING |
1 |
Rp8.064.500 |
| |
| 45 |
02162-0508A-000
SUB: 02162B0508AN000 |
SCREW |
2 |
Rp3.500 |
| |
| 46 |
38910-58M10-000 |
CONTROLLER ASSY, AIR BAG |
1 |
Rp5.350.500 |
| |
| 47 |
38919-68L00-000 |
BOLT, AIR BAG CONTROLLER |
3 |
Rp27.500 |
| |
| 48 |
38930-57L00-000 |
SENSOR ASSY, FORWARD |
1 |
Rp174.500 |
| |
| 49 |
09115-06004-000 |
BOLT (6X16) |
1 |
Rp19.500 |
| |
