FIG.49 LOCK SET (5MT:GLX)

FIG.49 LOCK SET (5MT:GLX)
No No. Part Description Qty Price Per Pcs Remarks
1-1 37019M66R11-000 LOCK SET, AUTO STEERING 1 Rp392.000
1-2 37019M55R90-000 LOCK SET, AUTO STEERING 1 Rp218.000
2 37152M75J00-000 .BOLT,STEERING LOCK 1 Rp16.000
3 37145M79M10-000 BLANK KEY 2 Rp301.500
4 37100M68PB1-000
SUB: 37100M68PA0-000		 LOCK ASSY, AUTO STEERING 1 Rp2.313.500
5 37290M68P03-000
SUB: 37290M68P01-000		 SWITCH ASSY, ENGINE START 1 Rp655.500
6-1 37172M68P51-000 REMOCON ASSY, KLS 2 Rp1.242.500
6-2 37172M50S10-000 REMOCON ASSY, KLS 2 Rp744.500

*Harga dapat berubah sewaktu-waktu tanpa pemberitahuan terlebih dahulu.
