FUTURA SL415

Preview Engine Transmission Electrical Suspension Body
< KEMBALI KE THUMBNAIL FIG.56 FRONT PANELFIG.57 FRONT FLOORFIG.58 SIDE BODY PANELFIG.59 ROOF PANELFIG.60 DECK FLOOR MEMBER (PICK UP)FIG.61 DECK FLOOR MEMBER (MINI BUS)FIG.62 DECK FLOOR (PICK UP:LOW FLOOR)FIG.63 DECK FLOOR (PICK UP:FLAT FLOOR)FIG.64 DECK FLOOR (MINI BUS)FIG.65 DECK GATE (PICK UP)FIG.66 FRONT BUMPER AND GRILLEFIG.67 MUD FLAP AND TIRE CARRIERFIG.68 BATTERY BOXFIG.69 INSTRUMENT PANELFIG.70 FRONT WINDOWFIG.71 FRONT DOOR PANELFIG.72 FRONT DOOR LOCKFIG.73 FRONT DOOR GLASSFIG.74 REAR DOOR LOCK (MINI BUS)FIG.75 BACK DOOR LOCK (MINI BUS)FIG.76 FUEL TANKFIG.77 FUEL TANK INLETFIG.78 SEAT (PICK UP)FIG.79 SEAT (MINI BUS)FIG.80 SEAT BELT

FIG.79 SEAT (MINI BUS)

FIG.79 SEAT (MINI BUS)
No No. Part Description Qty Price Per Pcs Remarks
1 DISCONTINUE
SUB: 85105-77550L000		 CUSHION SUB ASSY, RH 1 -
2 8518077550-G91 TRIM, CUSHION RH 1 -
3 DISCONTINUE
SUB: 85305-77550L000		 BACK SUB ASSY, RH 1 -
4 85380-77550-G91 TRIM, BACK RH 1 -
5 DISCONTINUE
SUB: 85210B85501N000		 RECLINING ASSY, RH 1 -
6 01570-0820B-000
SUB: 01570-0816A-000		 BOLT 8 Rp31.000
7 85211-84000-5PK KNOB, RECLINING (BLACK) 2 Rp51.500
8 DISCONTINUE
SUB: 03211-0408A-000		 SCREW 2 -
9 DISCONTINUE
SUB: 85221B84000N000		 COVER, RECLINING RH (BLACK) 1 -
10 03241-0512A-000
SUB: 03241B0512AN000		 SCREW 2 Rp3.500
11 09161-08006-000 WASHER (8X14X3) 2 Rp16.000
12 08332-1106A-000
SUB: 08332B1106AN000		 E RING 2 Rp8.500
13 DISCONTINUE
SUB: 85410-77553-000		 PANEL, SEAT RISER RH 1 -
14 85427-77500-000 .INSULATOR, RH 1 -
15 85428-77500-000
SUB: 85428B77500N000		 .WEATHERSTRIP, RH 1 Rp331.000
16 86610-77550-000
SUB: 86610-77550L000		 ADJUSTER, OUTER 1 Rp265.000 RH SEAT
17 86630-77550-000
SUB: 86630-77550L000		 ADJUSTER, INNER 1 Rp157.000 RH SEAT
18 DISCONTINUE
SUB: 01580-0612A-000		 BOLT 8 -
19 08316-2006A-000 NUT 8 Rp16.500
20 DISCONTINUE
SUB: 85106-77550L000		 CUSHION SUB ASSY, LH 1 -
21 85680-77550-G91 TRIM, CUSHION LH 1 -
22 DISCONTINUE
SUB: 85306-77550L000		 BACK SUB ASSY, LH 1 -
23 85880-77550-G91 TRIM, BACK LH 1 -
24 DISCONTINUE
SUB: 85710B85501N000		 RECLINING ASSY, LH 1 -
25 DISCONTINUE
SUB: 85721-84000-5PK		 COVER, RECLINING LH (BLACK) 1 -
26 85910-775A0-000 PANEL, SEAT RISER LH 1 -
27 85927-77500-000 .INSULATOR, LH 1 -
28 85928-77500-000
SUB: 85928B77500N000		 .WEATHERSTRIP, LH 1 Rp331.000
29 86610-77550-000
SUB: 86610-77550L000		 ADJUSTER, OUTER 1 Rp265.000 LH SEAT
30 86830-77550-000
SUB: 86830B77550N000		 ADJUSTER, INNER 1 Rp162.000 LH SEAT
31 DISCONTINUE
SUB: 86650-85000-000		 LOCK, SEAT CUSHION 3 -
32 DISCONTINUE
SUB: 01580-0616A-000		 BOLT 14 -
33 09387-19001-000
SUB: 09387B19001N000		 RING 0 Rp9.000
34 85155-77500-000 PAD, FRONT 2 -
35 85156-77500-000 PAD, REAR 1 -
36 85156-77550-000 PAD, REAR 1 -

*Harga dapat berubah sewaktu-waktu tanpa pemberitahuan terlebih dahulu.
