FIG.69 INSTRUMENT PANEL

FIG.69 INSTRUMENT PANEL
No No. Part Description Qty Price Per Pcs Remarks
1 73111-77500-6GL
SUB: 73111-77500L6GL		 PANEL, INSTRUMENT (BLACK) 1 Rp1.199.000
2 09118-06045-000 BOLT, SIDE (6X20) 2 Rp17.000
3 62381-79000-000 NUT, INSTRUMENT PANEL 1 Rp27.500
4 02142-0616A-000
SUB: 02142B0616AN000		 SCREW, LOWER 1 Rp3.000
5 02142-0616A-000
SUB: 02142B0616AN000		 SCREW 6 Rp3.000
6 73410-77500-6GL
SUB: 73410-77500L6GL		 LID, GLOVE BOX (BLACK) 1 Rp113.500
7 73415-77500-6GL
SUB: 73415B77500N6GL		 .LOCK, LID (BLACK) 1 Rp19.500
8 73416-77501-000 .SPRING, LOCK 1 Rp36.500
9 73431-77500-5ES
SUB: 73431-77500L5ES		 COVER, GLOVE BOX (BLACK) 1 Rp130.000
10 73421-85001-000 PIN, GLOVE BOX LID HINGE 1 Rp25.500
11 09148-05013-000
SUB: 09148-05004-000		 NUT, GLOVE BOX COVER 2 Rp13.500
12 09409-11301-000 CLIP, GLOVE BOX COVER 2 Rp18.500
13 03241-0512A-000
SUB: 03241B0512AN000		 SCREW, GLOVE BOX COVER 2 Rp3.500
14 73311-77500-5PK PANEL, METER CLUSTER (BLACK) 1 Rp460.000
15 89810-77500-6GL ASHTRAY, FRONT (BLACK) 1 Rp463.000
16 03241-0510A-000 SCREW, ASHTRAY 3 Rp8.000
17 09148-05013-000
SUB: 09148-05004-000		 NUT, ASHTRAY 2 Rp13.500
18 03241-0512A-000
SUB: 03241B0512AN000		 SCREW, METER CLUSTER 6 Rp3.500
19 09148-05013-000
SUB: 09148-05004-000		 NUT, METER CLUSTER 6 Rp13.500
20 73320-77500-6GL
SUB: 73320-77500L6GL		 COVER, RESERVOIR TANK (BLACK) 1 Rp123.500
21 73811-77500-6GL
SUB: 73811-77500L6GL		 CAP, CENTER (BLACK) 1 Rp30.500
22 73813-77500-6GL
SUB: 73813-77500L6GL		 CAP, RH (BLACK) 1 Rp31.000
23 73815-77500-6GL
SUB: 73815-77500L6GL		 CAP, LH (BLACK) 1 Rp31.000
24 73630-85200-5PK BOX, HEADLAMP HOUSING (BLACK) 2 Rp410.000
25 73632-85000-000 .PAD, HOUSING 2 Rp74.500
26 03541-0412A-000
SUB: 03541B0412AN000		 SCREW 8 Rp3.500
27-1 75811-77500-5ES
SUB: 75811B77500N5ES		 BOX, CENTER CONSOLE (BLACK) 1 Rp208.500 W/PICK UP
27-2 DISCONTINUE
SUB: 75811B77551N5ES		 BOX, CENTER CONSOLE (BLACK) 1 - W/MINI BUS
28 02162-0620A-000 SCREW, ENGINE ROOM CTR MEMBER 2 Rp5.500
29-2 02142-0610A-000
SUB: 02142B0610AN000		 SCREW, CONSOLE BOX 2 Rp3.500 W/MINI BUS
29-1 02142-0610A-000
SUB: 02142B0610AN000		 SCREW, CONSOLE BOX 1 Rp3.500 W/PICK UP
30 DISCONTINUE
SUB: 73821-77500L000		 STAY, CENTER 1 -
31 03241-0510A-000 SCREW, STAY 2 Rp8.000
32 73610-50A00-5ES LOUVER, CTR VENTILATOR (BLACK) 1 Rp523.000
33 03541-0412A-000
SUB: 03541B0412AN000		 SCREW, LOUVER 2 Rp3.500
34 73230-70A00-5PK LOUVER, VENT SIDE (BLACK) 1 Rp210.500
35 73640-50A00-5ES LOUVER, SIDE VENT LH (BLACK) 1 Rp307.000
36 03541-0412A-000
SUB: 03541B0412AN000		 SCREW 2 Rp3.500
37 DISCONTINUE
SUB: 74518B77500N000		 POCKET, HTR CONT 1 -
38 03541-0412A-000
SUB: 03541B0412AN000		 SCREW, HTR CONT 2 Rp3.500

*Harga dapat berubah sewaktu-waktu tanpa pemberitahuan terlebih dahulu.
