FIG.57 FRONT FLOOR

FIG.57 FRONT FLOOR
No No. Part Description Qty Price Per Pcs Remarks
1-2 DISCONTINUE
SUB: 61100B775E0N000		 PANEL ASSY, FRONT FLOOR 1 - W/PICK UP:FLAT FLOOR
1-3 DISCONTINUE
SUB: 61100B775F0N000		 PANEL ASSY, FRONT FLOOR 1 - W/MINI BUS
1-1 DISCONTINUE
SUB: 61100B775D0N000		 PANEL ASSY, FRONT FLOOR 1 - W/PICK UP:LOW FLOOR
2 09250-30002-000
SUB: 72999-67H00-000		 CAP, FLOOR DRAIN 2 Rp5.500
3-1 DISCONTINUE
SUB: 75410B77500N000		 MEMBER, ENGINE ROOM CENTER 1 - W/PICK UP
3-2 DISCONTINUE
SUB: 75410B77550N000		 MEMBER, ENGINE ROOM CENTER 1 - W/MINI BUS
4 02162-0616A-000
SUB: 02162-0616C-000		 BOLT, MEMBER 2 Rp3.000
5 09250-20034-000
SUB: 09250-20009-000		 CAP, IDLE SCREW 2 Rp35.000
6 DISCONTINUE
SUB: 75421-77500L000		 INSULATOR, CENTER MEMBER 1 -
7-1 65400-77501-000
SUB: 65400-77501L000		 PANEL ASSY, CAB BACK 1 Rp3.275.500 W/PICK UP:LOW FLOOR
7-2 DISCONTINUE
SUB: 65400B77511N000		 PANEL ASSY, CAB BACK 1 - W/PICK UP:FLAT FLOOR
8 DISCONTINUE
SUB: 65511B77551N000		 PANEL, REAR PILLAR INNER RH 1 - W/MINI BUS
9 DISCONTINUE
SUB: 65561B77551N000		 PANEL, REAR PILLAR INNER LH 1 - W/MINI BUS
10 DISCONTINUE
SUB: 65531-77500-000		 REINF, SEAT BELT UPPER RH 1 - W/MINI BUS
11 DISCONTINUE
SUB: 65581-77500-000		 REINF, SEAT BELT UPPER LH 1 - W/MINI BUS
12 65541-77500-000 BRACKET, SEAT BELT LOWER 2 - W/MINI BUS
13 75415-77330-000 SUPPORT, FRONT SEAT EXTENSION 1 - W/PICK UP
14 02162-0616A-000
SUB: 02162-0616C-000		 BOLT, SEAT SUPPORT 4 Rp3.000 W/PICK UP
15 09250-25007-000 PLUG, SILL SIDE INNER FRONT 2 Rp10.500
16 09250-25007-000 PLUG, SILL SIDE INNER REAR 2 Rp10.500
17 DISCONTINUE
SUB: 84761-50X50-000		 SEAL, FRONT FLOOR SIDE 2 - CUT AS REQUIRED
18 DISCONTINUE
SUB: 84761-50X50-000		 SEAL, SEAT BELT CTR 2 - W/MINI BUS
19 DISCONTINUE
SUB: 67751B77300N000		 MEMBER, REAR PILLAR 1 - W/MINI BUS
20 65811-775D0-000 BRACKET, AIR CLEANER NO.2 1 -
21 65812-775D0-000 BRACKET, AIR CLEANER NO.3 1 -
22 01550-0612B-000 BOLT, AIR CLEANER BRACKET 2 Rp16.500

*Harga dapat berubah sewaktu-waktu tanpa pemberitahuan terlebih dahulu.
