FIG.71 FRONT DOOR PANEL

FIG.71 FRONT DOOR PANEL
No No. Part Description Qty Price Per Pcs Remarks
1 68001-77500-000
SUB: 68001-77500L000		 PANEL ASSY, FRONT DOOR RH 1 Rp1.339.500
2 68002-77500-000
SUB: 68002-77500L000		 PANEL ASSY, FRONT DOOR LH 1 Rp1.339.500
3 69310-77700-000
SUB: 69310-77500L000		 HINGE, DOOR NO.1 2 Rp126.500
4 69340-77700-000
SUB: 69340-77500L000		 HINGE, DOOR NO.2 2 Rp126.500
5 09118-08060-000 BOLT (8X22) 16 Rp15.000
6 DISCONTINUE
SUB: 83911-77500L000		 COVER, FRONT DOOR SEALING 2 -
7-1 83710-77500-P11
SUB: 83710-77500LP11		 TRIM, DOOR RH (BLACK) 1 Rp246.000 W/PICK UP
7-2 DISCONTINUE
SUB: 83711-77500L000		 BOARD, DOOR RH 1 - W/MINI BUS
8-1 83720-77500-P11
SUB: 83720-77500LP11		 TRIM, DOOR LH (BLACK) 1 Rp246.000 W/PICK UP
8-2 DISCONTINUE
SUB: 83721-77500L000		 BOARD, DOOR LH 1 - W/MINI BUS
9 81810-77500-000 STOP, DOOR OPEN 2 Rp353.500
10 81831-70B00-000 PIN, OPEN STOP BODY 2 Rp40.500
11 01580-06303-000
SUB: 01580-0625A-000		 BOLT, DOOR OPEN STOP 4 Rp5.500
12 83714M62B00-000
SUB: 09409M08320-000		 CLIP 26 Rp14.500
13 84641-77500-000
SUB: 84641-77500L000		 WEATHERSTRIP, OPENING RH 1 Rp99.000
14 84651-77500-000
SUB: 84651-77500L000		 WEATHERSTRIP, OPENING LH 1 Rp95.500
15 84461-84000-5PK HANDLE, DR INSIDE PULL (BLACK) 2 -
16 03111-0625A-000 SCREW 4 Rp11.500
17 71851M70F00-000
SUB: 09148M06007-000		 NUT 4 Rp4.000
18 84645-77500-000
SUB: 84645-77500L000		 SEAL, FRONT DOOR DUST 2 Rp17.000
19 84701-77500-5PK
SUB: 84701B77500N5PK		 MIRROR ASSY, OUT REAR VIEW RH (BLACK) 1 Rp153.500
20 84702-77500-5PK
SUB: 84702B77500N5PK		 MIRROR ASSY, OUT REAR VIEW LH (BLACK) 1 Rp153.500
21 02142-0612A-000
SUB: 02142B0612AN000		 SCREW 4 Rp4.000
22 83817-77500-A02
SUB: 83817-77500LA02		 DECAL, DOOR UPPER RH 1 Rp25.500
23 83827-77500-A02
SUB: 83827-77500LA02		 DECAL, DOOR UPPER LH 1 Rp25.500
24 83816-77500-A98 DECAL, DOOR RH 1 - W/MINI BUS
25 83826-77500-A98 DECAL, DOOR LH 1 - W/MINI BUS
26 84752-85700-5PK GARNISH, SASH BRKT INR RH (BLACK) 1 Rp75.500
27 84757-85700-5PK GARNISH, SASH BRKT INR LH (BLACK) 1 Rp75.500

*Harga dapat berubah sewaktu-waktu tanpa pemberitahuan terlebih dahulu.
