FUTURA SL415

Preview Engine Transmission Electrical Suspension Body
< KEMBALI KE THUMBNAIL FIG.56 FRONT PANELFIG.57 FRONT FLOORFIG.58 SIDE BODY PANELFIG.59 ROOF PANELFIG.60 DECK FLOOR MEMBER (PICK UP)FIG.61 DECK FLOOR MEMBER (MINI BUS)FIG.62 DECK FLOOR (PICK UP:LOW FLOOR)FIG.63 DECK FLOOR (PICK UP:FLAT FLOOR)FIG.64 DECK FLOOR (MINI BUS)FIG.65 DECK GATE (PICK UP)FIG.66 FRONT BUMPER AND GRILLEFIG.67 MUD FLAP AND TIRE CARRIERFIG.68 BATTERY BOXFIG.69 INSTRUMENT PANELFIG.70 FRONT WINDOWFIG.71 FRONT DOOR PANELFIG.72 FRONT DOOR LOCKFIG.73 FRONT DOOR GLASSFIG.74 REAR DOOR LOCK (MINI BUS)FIG.75 BACK DOOR LOCK (MINI BUS)FIG.76 FUEL TANKFIG.77 FUEL TANK INLETFIG.78 SEAT (PICK UP)FIG.79 SEAT (MINI BUS)FIG.80 SEAT BELT

FIG.67 MUD FLAP AND TIRE CARRIER

FIG.67 MUD FLAP AND TIRE CARRIER
No No. Part Description Qty Price Per Pcs Remarks
1 72210-77500-000
SUB: 72210-77500L000		 PANEL, FRONT RH 1 Rp48.000
2 72220-77500-000
SUB: 72220-77500L000		 PANEL, FRONT LH 1 Rp48.000
3 57631-52002-000 PLATE, ATTACHING 2 Rp37.000
4 72231-77500-000
SUB: 72231-77500L000		 FLAP, FRONT MUD 2 Rp41.000
5 02142-0616A-000
SUB: 02142B0616AN000		 SCREW 4 Rp3.000
6 03141-0616A-000 SCREW 8 Rp19.500
7 09148-06006-000 NUT, FRONT MUD 8 Rp11.500
8 72231-77500-000
SUB: 72231-77500L000		 FLAP, REAR MUD 2 Rp41.000 W/PICK UP
9 57631-52002-000 PLATE, ATTACHING 2 Rp37.000 W/PICK UP
10 72263-77550-000
SUB: 72263-77500L000		 FENDER, DECK REAR RH 1 Rp37.000 W/PICK UP
11 72264-77550-000
SUB: 72264-77500L000		 FENDER, DECK REAR LH 1 Rp37.000 W/PICK UP
12-1 DISCONTINUE
SUB: 72265-77500L000		 STAY, DECK SIDE SKIRT 2 - W/PICK UP:LOW FLOOR
12-2 72265-77510-000 STAY, DECK SIDE SKIRT 2 - W/PICK UP:FLAT FLOOR
13 01550-0612B-000 SCREW, DECK REAR FENDER 8 Rp16.500 W/PICK UP
14 08310-0006A-000
SUB: 08310B0006AN000		 NUT, DECK REAR FENDER 8 Rp2.500 W/PICK UP
15 71510-77500-000
SUB: 71510-77500L000		 CARRIER, SPARE TIRE 1 Rp194.500
16-1 71530-77300-000
SUB: 71530-77300L000		 BOLT, SPARE TIRE CARRIER (L:260) 1 Rp30.500 W/PICK UP:LOW FLOOR W/MINI BUS
16-2 71530-77501-000
SUB: 71530B77510N000		 BOLT, SPARE TIRE CARRIER (L:360) 1 Rp15.000 W/PICK UP:FLAT FLOOR
17 09111-08044-000 BOLT 2 Rp18.000
18 72267-77510-000
SUB: 72267B77510N000		 BRACKET, DECK REAR FENDER RH 1 Rp37.000 W/PICK UP:FLAT FLOOR
19 72268-77510-000
SUB: 72268B77510N000		 BRACKET, DECK REAR FENDER LH 1 Rp37.000 W/PICK UP:FLAT FLOOR
20 75311-77500-000 SILENCER, FRONT FLOOR 1 -

*Harga dapat berubah sewaktu-waktu tanpa pemberitahuan terlebih dahulu.
