FIG.204 3RD SEAT (TYPE 1:GC415V:GLX)

No	No. Part	Description	Qty	Price Per Pcs
1	DISCONTINUE SUB: 86401-61JA0-AYK	HEADRESTRAINT ASSY	1	-
2	86490-61JA0-000	CABLE, SEAT LOCK	1	Rp34.000
3	86620-60KA0-000 SUB: 86620-61JA0-000	LEG, RH	1	Rp133.000
4	86640-60KA0-000 SUB: 86640-61JA0-000	LEG, LH	1	Rp133.000
5	86876-61JA0-000	ROD	1	Rp19.500
6	86877-61JA0-000	BUSH	4	Rp11.500
7	87105-61JJ1-000 SUB: 87105-61JJ0-000	CUSHION SUB ASSY, RH	1	Rp815.000
8	DISCONTINUE SUB: 87180-61JJ0-AYH	TRIM, CUSHION RH	1	-
9	87211-61JA0-R8H	KNOB, RECLINING RH (BEIGE)	1	Rp8.000
10	87221-61JA0-R8H	COVER, RECLINING OUTSIDE (BEIGE)	1	Rp27.500
11	87241-61JJ0-R8H	COVER, RECLINING INSIDE (BEIGE)	1	Rp31.000
12	87270-61JA0-000	BAND	1	Rp122.000
13	87285-61JA0-000	COVER, LOCK	1	Rp49.000
14	87288-61JA0-000	PIN	2	Rp29.500
15	08316-1010A-000 SUB: 08316B1010AN000	NUT	2	Rp3.500
16	85341-58J00-P4Z	GUIDE, HEADRESTRAINT (GRAY)	1	Rp75.000
17	85840-58J00-P4Z	GUIDE, HEADRESTRAINT (GRAY)	1	Rp144.000
18	85546-61JE0-000	BUSH, ARMREST	2	Rp9.500
19	DISCONTINUE SUB: 87305-61JL0-000	BACK SUB ASSY, RH	1	-
20	DISCONTINUE SUB: 87380-61JL1-AYH	TRIM, BACK RH	1	-
21	DISCONTINUE SUB: 87501-61JL0-T1K	ARMREST ASSY (BEIGE)	1	-
22	87521-61JL0-000	BOLT, ARMREST HINGE	1	Rp45.000
23	DISCONTINUE SUB: 87522-61JL0-000	BOLT, ARMREST STOPPER	1	-
24	87590-61JL0-R8H	BOARD, ARMREST (BEIGE)	1	Rp168.000
25	87460-61JA0-000	LOCK ASSY, RH	1	Rp546.500
26	01550-1020A-000	BOLT	4	Rp21.000
27	03241-0508A-000	SCREW	6	Rp10.500
28	DISCONTINUE SUB: 85293-61H00-000	BUSH	1	-
29	DISCONTINUE SUB: 86401-61JA0-AYK	HEADRESTRAINT ASSY	1	-
30	86490-61JA0-000	CABLE, SEAT LOCK	1	Rp34.000
31	86620-60KA0-000 SUB: 86620-61JA0-000	LEG, RH	1	Rp133.000
32	86640-60KA0-000 SUB: 86640-61JA0-000	LEG, LH	1	Rp133.000
33	86876-61JA0-000	ROD	1	Rp19.500
34	86877-61JA0-000	BUSH	4	Rp11.500
35	87106-61JA1-000 SUB: 87106-61JA0-000	CUSHION SUB ASSY, LH	1	Rp678.000
36	DISCONTINUE SUB: 87680-61JA0-AYH	TRIM, CUSHION LH	1	-
37	87270-61JA0-000	BAND	1	Rp122.000
38	87288-61JA0-000	PIN	2	Rp29.500
39	08316-1010A-000 SUB: 08316B1010AN000	NUT	2	Rp3.500
40	85341-58J00-P4Z	GUIDE, HEADRESTRAINT (GRAY)	1	Rp75.000
41	85840-58J00-P4Z	GUIDE, HEADRESTRAINT (GRAY)	1	Rp144.000
42	87306-61JA1-000 SUB: 87306-61JA0-000	BACK SUB ASSY, LH	1	Rp754.000
43	DISCONTINUE SUB: 87880-61JB1-AYH	TRIM, BACK LH	1	-
44	87711-61JA0-R8H	KNOB, RECLINING LH (BEIGE)	1	Rp8.000
45	87721-61JA0-R8H	COVER, RECLINING OUTSIDE (BEIGE)	1	Rp27.000
46	87781-61JA0-R8H	COVER, HINGE LH (BEIGE)	1	Rp21.000
47	87785-61JA0-000	COVER, LOCK LH	1	Rp578.500
48	87960-60KA1-000 SUB: 87960-61JA0-000	LOCK ASSY, LH	1	Rp642.000
49	09116-06109-000	BOLT (6X12)	1	Rp20.500
50	01550-1020A-000	BOLT	2	Rp21.000
51	03241-0508A-000	SCREW	5	Rp10.500
52	87870-76AC0-000	STRIKER,3RD	2	Rp343.000
53	01551-1020A-000	BOLT	4	Rp18.000
54	01551-1020A-000	BOLT	12	Rp18.000
55	09387-19001-000 SUB: 09387B19001N000	RING	0	Rp9.000
