FIG.190A EMISSION CONTROL

FIG.190A EMISSION CONTROL
No No. Part Description Qty Price Per Pcs Remarks
1 18114M76M00-000 VALVE, CANISTER PURGE 1 Rp322.500
2 18351M68P00-000 PIPE, PURGE RH 1 Rp233.000
3 18352M68P00-000 PIPE, PURGE 1 Rp265.500
4 18560M68P00-000 CANISTER 1 Rp385.000
5 18561M55R00-000 HOSE, PURGE 1 Rp45.500
6 18564M66R00-000 HOSE, PURGE 1 Rp53.000
7 18567M68P01-000 HOSE, CANISTER AIR SUCTION 1 Rp18.500
8 18569M68P02-000 PIPE, CSTR AIR SUCTION 1 Rp117.500
9 09401M11432-000 CLIP (ID:11.1) 4 Rp6.000
10 09401M11432-000 CLIP (ID:11.1) 2 Rp6.000
11 08316-1006A-000 NUT 1 Rp2.000

*Harga dapat berubah sewaktu-waktu tanpa pemberitahuan terlebih dahulu.
