FIG.176A OIL PUMP

FIG.176A OIL PUMP
No No. Part Description Qty Price Per Pcs Remarks
1 16100M68P02-000
SUB: 16100M68P01-000		 PUMP ASSY, OIL 1 Rp1.471.500
2 16116-69GE0-000 .FILTER, OIL GALLERY 3 Rp66.000
3 16130M83P00-000 .ROTOR SET, OIL PUMP 1 Rp275.500
4 16141M68K00-000 .OIL SEAL, CRANKSHAFT FR (41X53X6) 1 Rp53.500
5 16150M68K01-000 .VALVE SET, OIL PUMP RELIEF 1 Rp48.000
6 09168-08016-000
SUB: 09168B08016N000		 .GASKET (8.2X14X1) 1 Rp25.000
7 01550-0816A-000
SUB: 01550B0816AN000		 .BOLT 1 Rp6.000
8 07130-0625A-000 .BOLT 8 Rp3.500
9 16118M74LB0-000 O RING, OIL PUMP CASE 1 Rp11.500
10 16119M68K00-000 O RING (D:2.5,ID:16.6) 1 Rp7.000
11 16550-58MA0-000
SUB: 16550B58MA0N000		 VALVE, OIL CONTROL 1 Rp695.500
12 09206-06005-000 PIN (6X11) 2 Rp14.500
13 DISCONTINUE
SUB: 01550B0612AN000		 BOLT 1 -
14 01550-0830A-000
SUB: 01550B0830AN000		 BOLT 13 Rp4.000
15 01550-0885A-000 BOLT 2 Rp5.500

*Harga dapat berubah sewaktu-waktu tanpa pemberitahuan terlebih dahulu.
