NEW BALENO

Preview Engine Transmission Electrical Suspension Body
< KEMBALI KE THUMBNAIL FIG.101A SHORT ENGINE ASSYFIG.105A ENGINE GASKET SETFIG.111A CYLINDER HEADFIG.112A CYLINDERFIG.115A OIL PANFIG.120A CRANKSHAFTFIG.122A CAM SHAFT/VALVEFIG.124A CAM CHAINFIG.128A ENGINE MOUNTING (5MT)FIG.128B ENGINE MOUNTING (4AT) FIG.130A INTAKE MANIFOLDFIG.142A THROTTLE BODYFIG.150A AIR CLEANERFIG.154A EXHAUST MANIFOLDFIG.156A MUFFLERFIG.160A FUEL PUMPFIG.172A DELIVERY PIPE/FUEL INJECTORFIG.176A OIL PUMPFIG.180A WATER PUMPFIG.184A RADIATORFIG.188A WATER HOSEFIG.190A EMISSION CONTROLFIG.199A LABEL

FIG.156A MUFFLER

FIG.156A MUFFLER
No No. Part Description Qty Price Per Pcs Remarks
1 14183M78L00-000 RING, SEAL EXH PIPE 2 Rp207.000
2 14190M68PA0-000 PIPE, EXH 1 Rp706.500
3 14492M72F00-000 SPRING, EXH PIPE 4 Rp50.500
4 09119-10073-000 BOLT (10X65) 4 Rp75.000
5 14232M68P00-000 INSULATOR, PARKING CABLE HEAT 1 Rp67.500
6 14231M74L00-000 INSULATOR, HEAT 1 Rp38.000
7 14250M68PA0-000 PIPE, EXH CENTER 1 Rp1.911.500
8 14281M60M10-000 MOUNTING, MUF 1 Rp47.500
9 14281M65M10-000 MOUNTING, MUF 1 Rp70.000
10 14281-80JA0-000 MOUNTING, MUF 2 Rp67.500
11 14357-72J00-000 NUT, HEAT INSULATOR 7 Rp14.500
12 09159M10049-000 NUT 2 Rp10.500
13 14182M79F11-000 GASKET 1 Rp14.000
14 14300M68PA0-000 MUFFLER 1 Rp2.545.000

*Harga dapat berubah sewaktu-waktu tanpa pemberitahuan terlebih dahulu.
