FIG.111A CYLINDER HEAD

FIG.111A CYLINDER HEAD
No No. Part Description Qty Price Per Pcs Remarks
1 11100M68PB0-000 HEAD ASSY, CYLINDER 1 Rp7.098.500
2 11115M74L00-001 .GUIDE, VALVE 16 Rp16.000
3 09248-18011-000 .PLUG (18X8) 3 Rp38.000
4 11216M68K10-000 .GASKET 3 Rp8.000
5 11128-69G01-000 .BOLT, CAMSHAFT HOUSING (6X39) 21 Rp24.000
6 09206-08001-000
SUB: 09206B08001N000		 .PIN (8X11) 16 Rp5.500
7 11112-53A00-000 PLUG, OIL VENTURI 1 Rp31.500
8 11117-69J00-000 BOLT, CYLINDER HEAD 10 Rp64.500
9 04211M13189-000 PIN 2 Rp9.000
10 11141M68P00-000 GASKET, CYL HEAD 1 Rp450.000
11 11170M83P10-000 COVER ASSY, CYLINDER HEAD 1 Rp1.138.000
12 11189M83P00-000 .GASKET, CYL HEAD COVER 1 Rp191.500
13 11178-69L00-000 BOLT, CYLINDER HEAD COVER 14 Rp23.000
14 09482-00653-000 SPARK PLUG (NGK,LKR6F-10) 4 Rp41.000
15 16910M68PA1-000 GAUGE, OIL LEVEL 1 Rp14.000
16 16920-50M01-000 CAP, OIL FILLER 1 Rp114.500

*Harga dapat berubah sewaktu-waktu tanpa pemberitahuan terlebih dahulu.
