KARIMUN WAGON R TIPE 1 & 2

Preview Engine Transmission Electrical Suspension Body
< KEMBALI KE THUMBNAIL FIG. 47 FRONT SUSPENSIONFIG. 48 FRONT DRIVE SHAFT (5MT)FIG. 48A FRONT DRIVE SHAFT (5AGS)FIG. 49 FRONT SUSPENSION FRAMEFIG. 50 REAR SUSPENSIONFIG. 51 REAR AXLEFIG. 52 ROAD WHEEL/TIRE (GA)FIG. 53 ROAD WHEEL/TIRE (GL,GX)FIG. 53A ROAD WHEEL/TIRE (GS)FIG. 54 STEERING WHEELFIG. 55 STEERING COLUMN (GA)FIG. 56 STEERING COLUMN (GL,GX,GS)FIG. 57 STEERING UNITFIG. 58 PEDAL/PEDAL BRACKET (TYPE 1)FIG. 58A PEDAL/PEDAL BRACKET (TYPE 2:5MT)FIG. 58B PEDAL/PEDAL BRACKET (TYPE 2:5AGS)FIG. 59 BRAKE MASTER CYLINDER (TYPE 1)FIG. 59A BRAKE MASTER CYLINDER (TYPE 2)FIG. 60 BRAKE PIPING FIG. 62 REAR WHEEL BRAKEFIG. 63 PARKING BRAKEFIG. 61 FRONT WHEEL BRAKE

FIG. 62 REAR WHEEL BRAKE

FIG. 62 REAR WHEEL BRAKE
No No. Part Description Qty Price Per Pcs Remarks
1 53101-67L20-000
SUB: 53101B67L20N000		 PLATE ASSY, RR BRAKE RH 1 Rp210.000
2 53141-67L20-000
SUB: 53141B67L20N000		 PLUG, BACKING PLATE 1 Rp11.000
3 53151-67L20-000
SUB: 53151B67L20N000		 BOLT, WHEEL CYLINDER 2 Rp10.500
4 53231-67L20-000
SUB: 53231B67L20N000		 SPRING, SHOE RETURN 1 Rp9.000
5 53232-67L20-000
SUB: 53232B67L20N000		 SPRING, SHOE RETURN LWR 1 Rp10.500
6 53241-67L20-000
SUB: 53241B67L20N000		 PIN, SHOE HOLD DOWN 2 Rp13.000
7 53242-67L20-000
SUB: 53242B67L20N000		 CUP, SHOE HOLD DOWN 2 Rp9.000
8 53243-67L20-000
SUB: 53243B67L20N000		 SPRING, SHOE HOLD DOWN 2 Rp11.000
9 53251-67L20-000
SUB: 53251B67L20N000		 SPRING, STRUT RETAINING RH 1 Rp7.000
10 53401-67L20-000
SUB: 53401B67L20N000		 CYLINDER ASSY, WHEEL 1 Rp224.000
11 52474-67L20-000
SUB: 52474B67L20N000		 •CAP, BLEEDER PLUG 1 Rp9.500
12 53810-67L20-000
SUB: 53810B67L20N000		 •CUP SET, RR WHEEL CYLINDER 1 Rp97.500
13 55151-67L20-000
SUB: 55151B67L20N000		 •PLUG, BLEEDER 1 Rp23.000
14 53701-67L20-000
SUB: 53701B67L20N000		 STRUT ASSY RH 1 Rp60.000
15 53751-67L20-000
SUB: 53751B67L20N000		 LEVER, PARKING RH 1 Rp49.500
16 53102-67L20-000
SUB: 53102B67L20N000		 PLATE ASSY, RR BRAKE LH 1 Rp210.000
17 53141-67L20-000
SUB: 53141B67L20N000		 PLUG, BACKING PLATE 1 Rp11.000
18 53151-67L20-000
SUB: 53151B67L20N000		 BOLT, WHEEL CYLINDER 2 Rp10.500
19 53231-67L20-000
SUB: 53231B67L20N000		 SPRING, SHOE RETURN 1 Rp9.000
20 53232-67L20-000
SUB: 53232B67L20N000		 SPRING, SHOE RETURN LWR 1 Rp10.500
21 53241-67L20-000
SUB: 53241B67L20N000		 PIN, SHOE HOLD DOWN 2 Rp13.000
22 53242-67L20-000
SUB: 53242B67L20N000		 CUP, SHOE HOLD DOWN 2 Rp9.000
23 53243-67L20-000
SUB: 53243B67L20N000		 SPRING, SHOE HOLD DOWN 2 Rp11.000
24 53261-67L20-000
SUB: 53261B67L20N000		 SPRING, STRUT RETAINING LH 1 Rp7.000
25 53401-67L20-000
SUB: 53401B67L20N000		 CYLINDER ASSY, WHEEL 1 Rp224.000
26 52474-67L20-000
SUB: 52474B67L20N000		 •CAP, BLEEDER PLUG 1 Rp9.500
27 53810-67L20-000
SUB: 53810B67L20N000		 •CUP SET, RR WHEEL CYLINDER 1 Rp97.500
28 55151-67L20-000
SUB: 55151B67L20N000		 •PLUG, BLEEDER 1 Rp23.000
29 53702-67L20-000
SUB: 53702B67L20N000		 STRUT ASSY LH 1 Rp60.000
30 53761-67L20-000
SUB: 53761B67L20N000		 LEVER, PARKING LH 1 Rp50.500
31 53200-67L20-000
SUB: 53200B67L20N000		 SHOE SET 1 Rp256.500
32 53753-67L20-000
SUB: 53753B67L20N000		 •E RING 2 Rp7.500
33 53118-82J00-000 BOLT,REAR BRAKE 8 Rp25.500

*Harga dapat berubah sewaktu-waktu tanpa pemberitahuan terlebih dahulu.
