FIG. 58A PEDAL/PEDAL BRACKET (TYPE 2:5MT)

FIG. 58A PEDAL/PEDAL BRACKET (TYPE 2:5MT)
No No. Part Description Qty Price Per Pcs Remarks
1 49400-67LA1-000
SUB: 49400-67LA0-000		 PEDAL, ACCELERATOR 1 Rp506.000
2 09159-08127-000 NUT 2 Rp11.000
3 49610-67L00-000
SUB: 49610B67L00N000		 PEDAL, BRAKE 1 Rp226.000
4 49710-67L00-000
SUB: 49710B67L00N000		 BRACKET, BRAKE PEDAL 1 Rp41.000
5 49751M58J00-000 PAD, PEDAL 1 Rp9.500
6 49871M80F00-000 SPACER, BRAKE PEDAL SHAFT 1 Rp8.500
7 49881M75J00-000 BOLT, BRAKE PEDAL SHAFT 1 Rp9.500
8 09306M13004-000
SUB: 09307M13005-000		 BUSH 2 Rp11.500
9 08316-1010A-000
SUB: 08316B1010AN000		 NUT 1 Rp3.500
10 01550-0816A-000
SUB: 01550B0816AN000		 BOLT 1 Rp6.000
11 49720-67L00-000
SUB: 49720B67L00N000		 BRACKET, CLUTCH PEDAL 1 Rp53.500
12 49751M58J00-000 PAD, PEDAL 1 Rp9.500
13 49810-67L00-000
SUB: 49810B67L00N000		 PEDAL, CLUTCH 1 Rp242.500
14 49871M80F00-000 SPACER, CLUTCH PEDAL SHAFT 1 Rp8.500
15 49881M75J00-000 BOLT, CLUTCH PEDAL SHAFT 1 Rp9.500
16 49891M50E00-000 SPRING, CLUTCH PEDAL 1 Rp10.500
17 09100M06150-000 BOLT (6X31) 1 Rp4.500
18 09306M13004-000
SUB: 09307M13005-000		 BUSH 2 Rp11.500
19 09321M06026-000 CUSHION 1 Rp4.500
20 09321-06033-000 CUSHION 1 Rp19.000
21 08310-0006A-000
SUB: 08310B0006AN000		 NUT 1 Rp2.500
22 08316-1010A-000
SUB: 08316B1010AN000		 NUT 1 Rp3.500
23 09159-08150-000 NUT 2 Rp16.500
24 01550-0816A-000
SUB: 01550B0816AN000		 BOLT 1 Rp6.000

*Harga dapat berubah sewaktu-waktu tanpa pemberitahuan terlebih dahulu.
