FIG. 47 FRONT SUSPENSION

FIG. 47 FRONT SUSPENSION
No No. Part Description Qty Price Per Pcs Remarks
1 45111-67L80-000
SUB: 45111B67L80N000		 KNUCKLE, STEERING RH 1 Rp411.500
2 45151-67L80-000
SUB: 45151B67L80N000		 KNUCKLE, STEERING LH 1 Rp411.500
3 41601-67L80-000
SUB: 41601B67L80N000		 STRUT ASSY, FR SUSPENSION RH 1 Rp737.500
4 41602-67L80-000
SUB: 41602B67L80N000		 STRUT ASSY, FR SUSPENSION LH 1 Rp737.500
5 41710-67L80-000
SUB: 41710B67L80N000		 SUPPORT, FRONT STRUT 2 Rp96.500
6 41741-82K00-000
SUB: 41741B82K00N000		 BEARING, FRONT STRUT 2 Rp58.500
7 09103-12051-000 BOLT (12X50) 4 Rp27.500
8 09159-08123-000 NUT 4 Rp20.500
9 09159-12068-000 NUT 4 Rp21.000
10 08310-0012A-000
SUB: 08310-00123L000		 NUT 2 Rp17.500
11 DISCONTINUE
SUB: 08321-01123L000		 LOCK WASHER 2 -
12 41111-67L90-000
SUB: 41111B67L90N000		 SPRING, FRONT COIL 2 Rp227.000
13-1 42110M67L00-000
SUB: 42110B67L00N000		 STOPPER ASSY, FRONT BUMP 2 Rp175.000 TYPE 1
13-2 DISCONTINUE
SUB: 42111-67L70-000		 STOPPER ASSY, FRONT BUMP 2 - TYPE 2
14 41231-67L80-000
SUB: 41231B67L80N000		 SEAT, COIL SPRING UPPER 2 Rp81.500
15 45201-67L81-000
SUB: 45201B67L80N000		 ARM ASSY, FRONT SUSPENSION RH 1 Rp381.000
16 45530-67L80-000
SUB: 45530B67L80N000		 •BUSHING, SUSPENSION ARM FRONT 1 Rp29.000
17 45202-67L81-000
SUB: 45202B67L80N000		 ARM ASSY, FRONT SUSPENSION LH 1 Rp381.000
18 45530-67L80-000
SUB: 45530B67L80N000		 •BUSHING, SUSPENSION ARM FRONT 1 Rp29.000
19 09135-12017-000 BOLT (12X65) 2 Rp33.000
20 09135-12018-000 BOLT (12X77) 2 Rp51.500
21 09159-12069-000 NUT 2 Rp23.000
22 09385-12002-000
SUB: 09385B12002N000		 CLIP 2 Rp4.500
23 43421-68K80-000
SUB: 43421B68K80N000		 HUB, FRONT WHEEL 2 Rp408.500
24 43440-68K10-000
SUB: 43440B68K10N000		 BEARING, FRONT WHEEL 2 Rp211.000
25 09119-12012-000 BOLT (12X38) 8 Rp14.500
26 09159-18008-000 NUT 2 Rp52.500
27 09160-18017-000
SUB: 09160B18017N000		 WASHER (18X35X4) 2 Rp13.000
28 08331-41629-000
SUB: 08331-4162A-000		 CIRCLIP 2 Rp27.000

*Harga dapat berubah sewaktu-waktu tanpa pemberitahuan terlebih dahulu.
