  3. KARIMUN WAGON R TIPE 1 & 2
  4. Suspension
  5. FIG. 53A ROAD WHEEL/TIRE (GS)

KARIMUN WAGON R TIPE 1 & 2

Preview Engine Transmission Electrical Suspension Body
< KEMBALI KE THUMBNAIL FIG. 47 FRONT SUSPENSIONFIG. 48 FRONT DRIVE SHAFT (5MT)FIG. 48A FRONT DRIVE SHAFT (5AGS)FIG. 49 FRONT SUSPENSION FRAMEFIG. 50 REAR SUSPENSIONFIG. 51 REAR AXLEFIG. 52 ROAD WHEEL/TIRE (GA)FIG. 53 ROAD WHEEL/TIRE (GL,GX)FIG. 53A ROAD WHEEL/TIRE (GS)FIG. 54 STEERING WHEELFIG. 55 STEERING COLUMN (GA)FIG. 56 STEERING COLUMN (GL,GX,GS)FIG. 57 STEERING UNITFIG. 58 PEDAL/PEDAL BRACKET (TYPE 1)FIG. 58A PEDAL/PEDAL BRACKET (TYPE 2:5MT)FIG. 58B PEDAL/PEDAL BRACKET (TYPE 2:5AGS)FIG. 59 BRAKE MASTER CYLINDER (TYPE 1)FIG. 59A BRAKE MASTER CYLINDER (TYPE 2)FIG. 60 BRAKE PIPING FIG. 62 REAR WHEEL BRAKEFIG. 63 PARKING BRAKEFIG. 61 FRONT WHEEL BRAKE

FIG. 53A ROAD WHEEL/TIRE (GS)

FIG. 53A ROAD WHEEL/TIRE (GS)
No No. Part Description Qty Price Per Pcs Remarks
1 43110-67L00-LTD
SUB: 43110B67L00NLTD		 TIRE (175/65 R14 82T) CHAMPIRO ECO 4 Rp1.072.000
2 43210-67L00-LTD
SUB: 43210B67L00NLTD		 WHEEL,AL SILVER Z554 14" (SILVER) 4 Rp1.712.500
3 43130-78030-000 VALVE (TR413) 4 Rp62.000
4-1 09159-12079-000
SUB: 09159B12050N000		 NUT 16 Rp23.500 TYPE 1
4-2 09159-12079-000 NUT 16 Rp23.500 TYPE 2
5 990H0-77MK0-SPT
SUB: 990H0B77MK0NSPT		 CAP WHEEL CENTRE EC-26 (CHROME) 4 Rp58.000
6 43110-67L80-000
SUB: 43110B67L80N000		 TIRE, SPARE (145/80R13 75T) 1 Rp936.000
7 43210-67L80-39M
SUB: 43210B67L80N39M		 WHEEL, SPARE (14X4 1/2J) (SILVER) 1 Rp522.500
8 43130-78030-000 VALVE (TR413) 1 Rp62.000
9-6 DISCONTINUE
SUB: 43226-73H10-000		 WEIGHT, WHEEL BALANCE (30GRAM) 0 -
9-9 DISCONTINUE
SUB: 43231-54G10-000		 WEIGHT, WHEEL BALANCE (45GRAM) 0 -
9-8 DISCONTINUE
SUB: 43228-73H10-000		 WEIGHT, WHEEL BALANCE (40GRAM) 0 -
9-7 DISCONTINUE
SUB: 43227-73H10-000		 WEIGHT, WHEEL BALANCE (35GRAM) 0 -
9-5 DISCONTINUE
SUB: 43225-73H10-000		 WEIGHT, WHEEL BALANCE (25GRAM) 0 -
9-4 DISCONTINUE
SUB: 43224-73H10-000		 WEIGHT, WHEEL BALANCE (20GRAM) 0 -
9-3 DISCONTINUE
SUB: 43223-73H10-000		 WEIGHT, WHEEL BALANCE (15GRAM) 0 -
9-2 DISCONTINUE
SUB: 43222-73H10-000		 WEIGHT, WHEEL BALANCE (10GRAM) 0 -
9-1 43221-73H10-000 WEIGHT, WHEEL BALANCE (5GRAM) 0 Rp33.000
10-1 DISCONTINUE
SUB: 43221-73H00-000		 WEIGHT, WHEEL BALANCE (5GRAM) 0 -
10-2 DISCONTINUE
SUB: 43222-73H00-000		 WEIGHT, WHEEL BALANCE (10GRAM) 0 -
10-3 DISCONTINUE
SUB: 43223-73H00-000		 WEIGHT, WHEEL BALANCE (15GRAM) 0 -
10-4 DISCONTINUE
SUB: 43224-73H00-000		 WEIGHT, WHEEL BALANCE (20GRAM) 0 -
10-5 DISCONTINUE
SUB: 43225-73H00-000		 WEIGHT, WHEEL BALANCE (25GRAM) 0 -
10-6 DISCONTINUE
SUB: 43226-73H00-000		 WEIGHT, WHEEL BALANCE (30GRAM) 0 -
10-7 DISCONTINUE
SUB: 43227-73H00-000		 WEIGHT, WHEEL BALANCE (35GRAM) 0 -
10-8 DISCONTINUE
SUB: 43228-73H00-000		 WEIGHT, WHEEL BALANCE (40GRAM) 0 -
10-9 DISCONTINUE
SUB: 43231-73H00-000		 WEIGHT, WHEEL BALANCE (45GRAM) 0 -
11 79161-67L80-000
SUB: 79161B67L80N000		 PLACARD, TIRE INFORMATION 1 Rp16.000

*Harga dapat berubah sewaktu-waktu tanpa pemberitahuan terlebih dahulu.
