KARIMUN WAGON R TIPE 1 & 2

Preview Engine Transmission Electrical Suspension Body

< KEMBALI KE THUMBNAIL FIG. 1 ENGINE GASKET SET FIG. 2 CYLINDER HEAD (TYPE 1)FIG. 2A CYLINDER HEAD (TYPE 2)FIG. 3 CYLINDER (TYPE 1)FIG. 3A CYLINDER (TYPE 2)FIG. 4 OIL PAN FIG. 5 ENGINE MOUNTING (5MT)FIG. 5A ENGINE MOUNTING (5AGS)FIG. 6 CRANKSHAFT (TYPE 1)FIG. 6A CRANKSHAFT (TYPE 2)FIG. 7 CAM SHAFT/VALVE FIG. 8 CAM CHAIN FIG. 9 INTAKE MANIFOLD (TYPE 1)FIG. 9A INTAKE MANIFOLD (TYPE 2)FIG. 10 THROTTLE BODY (TYPE 1)FIG. 10A THROTTLE BODY (TYPE 2)FIG. 11 AIR CLEANER (TYPE 1)FIG. 11A AIR CLEANER (TYPE 2)FIG. 12 EXHAUST MANIFOLD (TYPE 1)FIG. 12A EXHAUST MANIFOLD (TYPE 2)FIG. 13 MUFFLER FIG. 14 FUEL PUMP FIG. 15 DELIVERY PIPE/FUEL INJECTOR (TYPE 1)FIG. 15A DELIVERY PIPE/FUEL INJECTOR (TYPE 2)FIG. 16 OIL PUMP FIG. 17 WATER PUMP FIG. 18 RADIATOR FIG. 19 WATER HOSE (TYPE 1)FIG. 19A WATER HOSE (TYPE 2)FIG. 20 EMISSION CONTROL (TYPE 1)FIG. 20A EMISSION CONTROL (TYPE 2)FIG. 21 LABEL

FIG. 20A EMISSION CONTROL (TYPE 2)

FIG. 20A EMISSION CONTROL (TYPE 2)

No	No. Part	Description	Qty	Price Per Pcs	Remarks
1	18114-68M00-000	VALVE ASSY, DUTY FOR PURGE	1	Rp1.016.000
2	18117-84M00-000	BRACKET, PURGE VSV	1	Rp307.500
3	18564-67LB0-000	HOSE, PURGE (VSV TO INMF)	1	Rp16.000
4	09401-10409-000 SUB: 09401B10409N000	CLIP	2	Rp7.500
5	08316-1006A-000 SUB: 08316B1006AN000	NUT	1	Rp2.000
6	18340-67L00-000 SUB: 18340B67L00N000	PIPE, PURGE	1	Rp57.500
7	18560-59R00-000	CANISTER	1	Rp260.000
8-1	18561-67L30-000	HOSE, CANISTER INLET	1	Rp18.500	5MT
8-2	09355-56L02-180	HOSE, CANISTER INLET	1	Rp18.500	5AGS
9-1	18562-67L30-000	HOSE, PURGE (PIPE TO VSV)	1	Rp42.000	5MT
9-2	18562-67L20-000	HOSE, PURGE (PIPE TO VSV)	1	Rp41.000	5AGS
10	18571-65H20-000 SUB: 18571B65H20N000	CAP, CANISTER AIR	1	Rp11.000
11	09355-56L02-160	HOSE, CSTR TO PIPE	2	Rp17.000
12	09401-10409-000 SUB: 09401B10409N000	CLIP	4	Rp7.500
13	09401-10409-000 SUB: 09401B10409N000	CLIP	4	Rp7.500
14	DISCONTINUE SUB: 01550B0612AN000	BOLT	1	-
15	18590-67LB0-000	SENSOR, MAP	1	Rp182.500
16	01550-0620C-000	BOLT	1	Rp5.500

*Harga dapat berubah sewaktu-waktu tanpa pemberitahuan terlebih dahulu.
