KARIMUN WAGON R TIPE 1 & 2

Preview Engine Transmission Electrical Suspension Body

< KEMBALI KE THUMBNAIL FIG. 1 ENGINE GASKET SET FIG. 2 CYLINDER HEAD (TYPE 1)FIG. 2A CYLINDER HEAD (TYPE 2)FIG. 3 CYLINDER (TYPE 1)FIG. 3A CYLINDER (TYPE 2)FIG. 4 OIL PAN FIG. 5 ENGINE MOUNTING (5MT)FIG. 5A ENGINE MOUNTING (5AGS)FIG. 6 CRANKSHAFT (TYPE 1)FIG. 6A CRANKSHAFT (TYPE 2)FIG. 7 CAM SHAFT/VALVE FIG. 8 CAM CHAIN FIG. 9 INTAKE MANIFOLD (TYPE 1)FIG. 9A INTAKE MANIFOLD (TYPE 2)FIG. 10 THROTTLE BODY (TYPE 1)FIG. 10A THROTTLE BODY (TYPE 2)FIG. 11 AIR CLEANER (TYPE 1)FIG. 11A AIR CLEANER (TYPE 2)FIG. 12 EXHAUST MANIFOLD (TYPE 1)FIG. 12A EXHAUST MANIFOLD (TYPE 2)FIG. 13 MUFFLER FIG. 14 FUEL PUMP FIG. 15 DELIVERY PIPE/FUEL INJECTOR (TYPE 1)FIG. 15A DELIVERY PIPE/FUEL INJECTOR (TYPE 2)FIG. 16 OIL PUMP FIG. 17 WATER PUMP FIG. 18 RADIATOR FIG. 19 WATER HOSE (TYPE 1)FIG. 19A WATER HOSE (TYPE 2)FIG. 20 EMISSION CONTROL (TYPE 1)FIG. 20A EMISSION CONTROL (TYPE 2)FIG. 21 LABEL

FIG. 9A INTAKE MANIFOLD (TYPE 2)

FIG. 9A INTAKE MANIFOLD (TYPE 2)

No	No. Part	Description	Qty	Price Per Pcs	Remarks
1	11851-60B01-000 SUB: 11851B60B01N000	HOOK, ENGINE	1	Rp9.500
2	13110-67LB0-000	MANIFOLD, INTAKE	1	Rp797.000
3	13118-67LB0-000	•GASKET, INTAKE MANIFOLD	3	Rp10.500
4	13421-67LB0-000	•GASKET, THROTTLE BODY	1	Rp15.000
5	01550-0816A-000 SUB: 01550B0816AN000	BOLT (8X16)	1	Rp6.000
6	01421-0835A-000	STUD BOLT	2	Rp13.500
7	01550-0835A-000 SUB: 01550B0835AN000	BOLT	2	Rp3.500
8	08316-1008A-000 SUB: 08316B1008AN000	NUT	2	Rp3.500

*Harga dapat berubah sewaktu-waktu tanpa pemberitahuan terlebih dahulu.
