FIG. 11A AIR CLEANER (TYPE 2)

FIG. 11A AIR CLEANER (TYPE 2)

No	No. Part	Description	Qty	Price Per Pcs	Remarks
1	13176-68K50-000	BOLT, AIR CLEANER	1	Rp75.500
2	13700-52P10-000	CLEANER ASSY, AIR	1	Rp412.500
3	13780-76M00-000 SUB: 13780B76M00N000	•ELEMENT	1	Rp133.500
4	13783-54LA0-000 SUB: 13783B54LA0N000	•CLIP	2	Rp16.500
5	13877-68K50-000	•COLLAR, AIR CLEANER	1	Rp143.000
6	13878-68K50-000	•GROMMET, AIR CLEANER	1	Rp136.000
7	09136-06141-000	SCREW (6X25)	1	Rp17.000
8	13765-67LB0-000 SUB: 13765B67L01N000	PIPE, AIR CLEANER SUCTION	1	Rp26.500
9	13766-65L00-000 SUB: 13766B65L00N000	HOSE, AIR CLEANER SUCTION	1	Rp79.000
10	13871-73K00-000	GROMMET, AIR INTK	4	Rp22.500
11	13881-76M00-000	HOSE, AIR CLEANER OUTLET	1	Rp42.000
12	09402-70503-000 SUB: 09402-69511-000	CLAMP	2	Rp91.500
13	09409-08327-000	CLIP	2	Rp15.000
14	11190M76M00-000	UNION, BREATHER	1	Rp10.500
15	11191-67LA0-000 SUB: 11191B67LA0N000	HOSE, BREATHER	1	Rp35.500
16	11199M68K00-000 SUB: 09401M18404-000	CLIP	2	Rp11.000
17	13650-52G00-000	SENSOR, INLET AIR TEMP	1	Rp762.500

*Harga dapat berubah sewaktu-waktu tanpa pemberitahuan terlebih dahulu.
