KARIMUN WAGON R TIPE 1 & 2

Preview Engine Transmission Electrical Suspension Body

< KEMBALI KE THUMBNAIL FIG. 1 ENGINE GASKET SET FIG. 2 CYLINDER HEAD (TYPE 1)FIG. 2A CYLINDER HEAD (TYPE 2)FIG. 3 CYLINDER (TYPE 1)FIG. 3A CYLINDER (TYPE 2)FIG. 4 OIL PAN FIG. 5 ENGINE MOUNTING (5MT)FIG. 5A ENGINE MOUNTING (5AGS)FIG. 6 CRANKSHAFT (TYPE 1)FIG. 6A CRANKSHAFT (TYPE 2)FIG. 7 CAM SHAFT/VALVE FIG. 8 CAM CHAIN FIG. 9 INTAKE MANIFOLD (TYPE 1)FIG. 9A INTAKE MANIFOLD (TYPE 2)FIG. 10 THROTTLE BODY (TYPE 1)FIG. 10A THROTTLE BODY (TYPE 2)FIG. 11 AIR CLEANER (TYPE 1)FIG. 11A AIR CLEANER (TYPE 2)FIG. 12 EXHAUST MANIFOLD (TYPE 1)FIG. 12A EXHAUST MANIFOLD (TYPE 2)FIG. 13 MUFFLER FIG. 14 FUEL PUMP FIG. 15 DELIVERY PIPE/FUEL INJECTOR (TYPE 1)FIG. 15A DELIVERY PIPE/FUEL INJECTOR (TYPE 2)FIG. 16 OIL PUMP FIG. 17 WATER PUMP FIG. 18 RADIATOR FIG. 19 WATER HOSE (TYPE 1)FIG. 19A WATER HOSE (TYPE 2)FIG. 20 EMISSION CONTROL (TYPE 1)FIG. 20A EMISSION CONTROL (TYPE 2)FIG. 21 LABEL

FIG. 8 CAM CHAIN

FIG. 8 CAM CHAIN

No	No. Part	Description	Qty	Price Per Pcs	Remarks
1	12742-51K00-000 SUB: 12742B51K00N000	SPROCKET, CAMSHAFT TIMING EXH	1	Rp119.500
2	12722-67LA0-000 SUB: 12722B67LA0N000	BOLT, CAMSHAFT SPROCKET	1	Rp9.500
3	09206-05001-000	PIN (3.4X5X10)	1	Rp11.500
4-1	DISCONTINUE SUB: 12761-69LA0-000	CHAIN, TIMING	1	-	TYPE 1
4-2	12761-59R00-000	CHAIN, TIMING	1	Rp384.000	TYPE 2
5-1	12771-58M00-000	GUIDE, TIMING CHAIN	1	Rp172.000	TYPE 1
5-2	12771-59R00-000	GUIDE, TIMING CHAIN	1	Rp95.000	TYPE 2
6	01550-0616A-000 SUB: 01550B0616AN000	BOLT	2	Rp3.500
7	12781-69G00-000 SUB: 12781B69G00N000	JET, TIMING CHAIN	1	Rp24.500
8-1	12811-58M00-000	TENSIONER, TIMING CHAIN	1	Rp273.000	TYPE 1
8-2	12811-59R00-000	TENSIONER, TIMING CHAIN	1	Rp127.500	TYPE 2
9	12812M73G10-000	SPACER, TIMING CHAIN TENSIONER	1	Rp13.000
10	01550-0825A-000 SUB: 01550B0825AN000	BOLT	1	Rp3.500
11-1	12831-67L00-000 SUB: 12831B67L00N000	ADJUSTER ASSY, TENSIONER	1	Rp697.500	TYPE 1
11-2	12831-84MA0-000	ADJUSTER ASSY, TENSIONER	1	Rp946.500	TYPE 2
12	01550-0620B-000 SUB: 01550B0620AN000	BOLT	2	Rp3.500

*Harga dapat berubah sewaktu-waktu tanpa pemberitahuan terlebih dahulu.
