FIG.520A FRONT WHEEL BRAKE

FIG.520A FRONT WHEEL BRAKE
No No. Part Description Qty Price Per Pcs Remarks
1 55101M50S00-000 CALIPER ASSY, FR BRAKE RH 1 Rp1.435.500
2 55151M55K00-000 .PLUG, BLEEDER 1 Rp11.500
3 55234M69P00-000 .CLIP 2 Rp83.000
4 55830M69P01-000 .PISTON/SEAL SET 1 Rp115.000
5 55840M69P01-000 ..SEAL SET 1 Rp45.500
6 55156M66310-000 ...CAP, BLEEDER PLUG 1 Rp23.500
7 55850M72R00-000 .PIN/BOOT, SLIDING 1 Rp146.500
8 55201M60M00-000 ..BOOT, PIN 2 Rp23.000
9 55206M76G00-000 ..BOLT, PIN 2 Rp21.000
10 55102M50S00-000 CALIPER ASSY, FR BRAKE LH 1 Rp1.435.500
11 55151M55K00-000 .PLUG, BLEEDER 1 Rp11.500
12 55234M69P00-000 .CLIP 2 Rp83.000
13 55830M69P01-000 .PISTON/SEAL SET 1 Rp115.000
14 55840M69P01-000 ..SEAL SET 1 Rp45.500
15 55156M66310-000 ...CAP, BLEEDER PLUG 1 Rp23.500
16 55850M72R00-000 .PIN/BOOT, SLIDING 1 Rp146.500
17 55201M60M00-000 ..BOOT, PIN 2 Rp23.000
18 55206M76G00-000 ..BOLT, PIN 2 Rp21.000
19 55810M50S00-000 PAD SET 1 Rp1.144.500
20 55820M69P00-000 .SHIM SET 1 Rp302.500
21 55164M74L00-000 BOLT, BRAKE CALIPER 4 Rp17.000
22 55311M69P10-000 DISC, FR BRAKE 2 Rp990.500
23 55321M68P00-000 COVER, BRAKE DISC DUST RH 1 Rp30.000
24 55322M68P00-000 COVER, BRAKE DISC DUST LH 1 Rp30.000

*Harga dapat berubah sewaktu-waktu tanpa pemberitahuan terlebih dahulu.
